Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
122
CX-JTD8
< JACK >
J801 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J802 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J803 1-537-943-11 TERMINAL, S (S VIDEO OUT)
< COIL >
L800 1-410-470-11 INDUCTOR 10uH
L861 1-456-513-11 INDUCTOR 0uH
L862 1-410-397-21 INDUCTOR 1.1uH
L871 1-456-513-11 INDUCTOR 0uH
L872 1-414-741-11 INDUCTOR 10uH
< TRANSISTOR >
Q801 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q802 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q851 8-729-040-20 TRANSISTOR RT1P137L-TP
Q852 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q853 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q855 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q857 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R803 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R818 1-247-804-11 CARBON 75 5% 1/4W
R821 1-247-804-11 CARBON 75 5% 1/4W
R824 1-247-804-11 CARBON 75 5% 1/4W
R827 1-247-804-11 CARBON 75 5% 1/4W
R830 1-247-804-11 CARBON 75 5% 1/4W
R833 1-247-804-11 CARBON 75 5% 1/4W
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-429-11 CARBON 10K 5% 1/4W
R838 1-249-403-11 CARBON 68 5% 1/4W
R839 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
MISCELLANEOUS
**************
11
12
13
14
58
65
103
106 1-796-487-31 DECK, MECHANICAL (CWM43RR23)
253 1-693-615-21 TUNER (FM/AM)
254
0 303 1-775-787-62 CORD, POWER (EXCEPT E)
0 303 1-827-226-11 CORD, POWER (E)
509 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
653 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
0 655 1-477-263-11 OPTICAL TRAVERSE UNIT (DBU-1)
0 F911 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F912 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F913 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (T8AL/250V)
0 F914 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (T8AL/250V)
VIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
0 F915 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (T8AL/250V)
0 F916 1-533-472-12 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
0 F917 1-533-472-12 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
0 F918 1-533-472-12 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
0 F919 1-533-471-12 FUSE, GLASS TUBE (DIA. 5) (T4AL/250V)
0 F920 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F921 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
M741 A-4723-963-A MOTOR ASSY, TABLE
M751 A-4737-553-A MOTOR ASSY, LOADING
M961 1-763-072-11 FAN, DC
S711 1-477-680-11 ENCODER, ROTARY
(DISC TRAY ADDRESS DETECT)
0 T911 1-443-044-11 TRANSFORMER, POWER (EA)
0 T911 1-443-047-11 TRANSFORMER, POWER (EXCEPT EA)
************************************************************
ACCESSORIES
************
0 1-569-008-22 ADAPTOR, CONVERSION 2P
