Sony DSC-P72 - Jk Block (Jk-252); Control Switch Block (Rl-059)

2-6
DSC-P72
2-7. CONTROL SWITCH BLOCK (RL-059), ST-82 BOARD
2-6. MEMORY STICK CONNECTOR, JK BLOCK (JK-252)
1 Tapping screw
(1.7
× 4)
5 Tapping screw, p2
(1.7
× 5)
4 Memory stick connecto
r
2 Claw
7 JK block (JK-252) (39P)
8 JK block (JK-252)
3 JK block (JK-252) (10P)
6 Tape (Y)
Tape (Y)
SY-85 board
Attach the Tape (Y) as shown in the illustration.
Caution
2 Control switch block (RL-059)(10P)
3 Control switch block
(RL-059)
5 FP-643 flexible board
(12P)
1 Two claws
4 Two claws
6 ST-82 boar
d
