Sony DSC-P72 - Disassembly

2-1
SECTION 2
DISASSEMBLY
DSC-P72
COVER
COVER
HELP
HELP
The following flow chart shows the disassembly procedure.
1 2-1. CABINET (R) BLOCK ASSEMBLY .................................................
2 2-2. BLOCK LIGHT GUIDE PLATE, LCD MODULE,
CONTROL SWITCH BLOCK (SW-391), LITHIUM BATTERY .......
3 2-3. MAIN BLOCK ASSEMBLY .............................................................
4 2-4. UNIT PARTS (UA-002) ..................................................................
5 2-5. VIDEO LENS (ED02D), CCD BLOCK ASSEMBLY ........................
6 2-6. MEMORY STICK CONNECTOR, JK BLOCK (JK-252) .................
7 2-7. CONTROL SWITCH BLOCK (RL-059), ST-82 BOARD .................
8 2-8. SY-85 BOARD ................................................................................
(page 2-2)
(page 2-3)
(page 2-4)
(page 2-4)
(page 2-5)
(page 2-6)
(page 2-6)
(page 2-7)
PROCEDURE OF REMOVING SY-85 BOARD (SERVICE POSITION)
SY-85 board
service position
Discharging the Capacitor
