Sony DSC-P72 - Circuit Boards Location

2-9
DSC-P72
2-10.CIRCUIT BOARDS LOCATION
SY-085
SY-085 CCD IMAGER, CAMERA A/D CONVERTER, LENS DRIVE,
CAMERA DSP, VIDEO AMP, SH DSP, CLK GEN., FRONT CONTROL,
AUDIO I/O, LCD DRIVE, TIMING GEN., DC IN, DC-DC CONVERTER.,
CONNECTOR
ST-082 FLASH DRIVE
Board Name Function
ST-082
