Sony DSC-P72 - Board

2-7
DSC-P72
2-8. SY-85 BOARD
When removing the harness,
be sure to pull the harness up at the
right angle with the board while pressing
down the connector on the circuit board.
3 SY-85 board
2 Battery holder
(with terminal)
(4P)
1 Four screws(M2 × 3
)
Connector
Caution
