2-10E
DSC-P72
2-11.FLEXIBLE BOARDS LOCATION
FP-643
CONTROL SWITCH BLOC
K
(RL-059)
CONTROL SWITCH BLOCK
(SW-391)
JK BLOCK
(JK-252)
UNIT PARTS (UA-002)
The flexible boards contained in the video lens are not shown.
