4-5. MOUNTED PARTS LOCATION
no mark : side A
* mark : side B
ST-82 BOARD
* C503 A-3
* C504 A-3
* C505 A-4
* C506 A-2
* C507 A-1
C509 A-1
* C510 A-3
* C511 A-4
* C512 A-3
* CN501 A-2
* D502 A-1
* IC501 A-1
L501 A-1
* Q502 A-3
* Q503 A-3
* Q504 A-3
* Q505 A-2
Q506 A-1
* R501 A-2
* R502 A-3
* R503 A-3
* R504 A-3
* R505 A-3
* R506 A-3
* R508 A-4
* R509 A-2
* R510 A-1
* R511 A-1
R512 A-1
* T501 A-4
