Sony DVP-K800D - 2] CD Disc; 3] DVD Dual Layer Disc

5-20
5-3-3. [2] CD disc
When “[2] CD Disc “ is selected and a CD is inserted, the adjustment is performed in the order described below. The adjustment values are
saved in EEPROM.
CD adjustment procedure
LD ON Auto Loop Filter Offset
Spindle Start Auto Focus Offset
Tilt ON Auto Focus Gain
FOCUS ON Auto Tracking Gain
FOK Check Auto Loop Filter Offset
Pull in Memory
Auto Tracking Offset Jitter Check
FOK Check Servo Stop
Search Check
Tracking ON
Sled ON
CLVA
Lock Check
5-3-4. [3] DVD dual layer disc
When “[3] DVD Dual Layer Disc” is selected and the DVD dual layer disc is inserted, the adjustment is performed in the order described
below. The adjustment values of each layer are saved in EEPROM.
DVD dual layer adjustment procedure
(Layer 0)
LD ON
Spindle Start (Layer 1)
Tilt ON Focus Jump (L0→L1)
Focus ON FOK Check
FOK Check
Sled Move
Sled ON
Auto Tracking Offset CLVA
FOK Check Lock Check
Layer Check
Tracking ON
Sled ON Auto Focus Offset
AGC ON Auto Focus Gain
CLVA Auto Tracking Gain
Lock Check Auto EQ
Pull in Memory
Auto Focus Offset
Auto Tilt Offset Jitter Check
Auto Focus Offset
Auto Focus Gain Servo Stop
Auto Tracking Gain Search Check
Auto EQ
Layer Check
Jitter Check
