Sony DVP-K800D - Manual Adjustment (1)

5-24
0. FWD 32TJ 32 track jump (N track jump) forward
1. RVS 32TJ 32 track jump (N track jump) reverse
2. FWD 500TJ 500 track jump (fine searcj) forward
3. RVS 500TJ 500 track jump (fine searcj) reverse
4. FWD 10kTJ 10k track jump (direct search) forward
5. RVS 10kTJ 10k track jump (direct search) reverse
6. FJ0→1 Layer jump L0→L1, Tracking loop does not turn ON
7. FJ1→0 Layer jump L1→L0, Tracking loop does not turn ON
8. LJ0→1 Layer jump L0→L1, Tracking loop turns ON
9. LJ1→0 Layer jump L1→L0, Tracking loop turns ON
→. FWD 1TJ 1 track jump, forward
←. RVS 1TJ 1 track jump, reverse
5-4-5. Manual Adjustment (1)
Manual Adjust 1
SA.042807 SI.00 EMG.00
0. TRK. Offset
1. TRK. Offset2 (DVD)
2. TRK. Gain2 (CD)
3. Focus Gain
4. TRK. Gain
DVD SL 12cm
The manual adjustments in which jitter measurement is not performed, can be executed using this display. When any desired item number is
selected, present setting of the item is shown. The adjustment value can be increased or decreased using the arrow mark keys (↑→↓←). The
adjustment value is stored in EEPROM.
0. TRK. Offset The tracking offset adjustment is performed.
When adjusting a DVD, the tracking offset is canceled coarsely by SSI33P3720A with the peak bottom that is
measured by CXD8730Q. The fine tracking offset adjustment is performed within the CXD8730Q. This
adjustment sets the value for the fine adjustment. Because this is the adjustment within the CXD8730Q only,
the DC component of the tracking traverse is not chaned. When adjusting CD, this setting value only is changed.
1. TRK. Offset2 (DVD) The tracking offset adjustment of DVD is performed. (For SSI/33P3720A)
Adjustment range: Lower 4 bits = 7 to 1, 8 to F
( +175 to +25mV, 0 to -175mV)
2. TRK. Gain2 (CD) The simple AGC adjustment of CD is performed.
Adjustment range:Higher 4 bits = x000 to x101(binary)
3. Focus Gain Focus gain is adjusted.
4. TRK. Gain Tracking gain is adjusted.
When tracking gain in CD mode is adjusted, the simple AGC is set in which 5 different steps of -3.2, -1.6, 0,
+1.6, +3.2 dB can be set in CXA2555Q based on the peak bottom that is measured by CXD8730Q. (Auto
Tracking Offset) Then the setting inside CXD8730Q is performed. (Auto Tracking Gain) The setting inside
CXD8730Q can be performed by this adjustment.
When tracking gain in DVD mode is adjusted, only the setting inside CXD8730Q can be performed.
