Sony DVP-S7700 Service Manual

2-52-5 E
2-14. CIRCUIT BOARDS LOCATION
POWER BLOCK
(HS-930SH)
(SWITCHING REGULATOR)
MB-84
(SIGNAL PROCESS/
SERVO)
HP-120
(HEAD PHONE)
PW-120
(IR/POWER SWITCH)
FR-160
(FUNCTION SWITCH)
DC MOTOR
(SPINDLE)
DR-88
(DOOR SENSOR)
CN-113
(DOOR MOTOR)
TK-47
(RF/SERVO)
YS-19
(COMPONENT
VIDEO)
AU-218
(AUDIO)
FG-43
(SLED)
PS-421
(AUDIO POWER)
FP-75
(FL DRIVER)
FL-108
(FUNCTION SWITCH)
ER-8 (AEP, UK)
(EURO AV)

Sony DVP-S7700 Specifications

General

Type	DVD player
Video Output	Composite, S-Video, Component
Digital Output	Coaxial, Optical
Signal-to-Noise Ratio	115 dB
Audio Format	Dolby Digital, DTS
Disc formats	CD, CD-R, CD-RW
Output Resolution	480p
Audio Output	Stereo
Output Level	2.0 Vrms
Dimensions	430 x 98 x 360 mm
DAC	24-bit/96kHz
Channels	2
