6-6-3. Manual Control 1
Manual Control 1
SA.000000 SI.00 EMG.00
0. LD off 7. CLVA
1. SP off 8. CAV
2. Tilt off 9. Home
3. Focus off →. Sled FWD
4. Track off ←. Sled RVS
5. Sled off ↑ . Tilt Up
6. AGC off ↓ . Tilt Down
DVD SL 12cm
Figure 13
On this screen, turn on/off servo operation items necessary for
playing.
Normally, turn on the items from 0 sequentially, and normal trace
is executed at CLVA. In the tracking status, the sector address (or
time code (at CD)) is displayed.
If not displayed, the spindle is not locked, which means a failure.
In case of spindle system failure or no RF, the spindle system may
run, overriding the control.
In this case, do not press the CLVA.
0. LD : Turn on/off the laser diode.
1. SP : Turn on/off the spindle.
At SP ON, the spindle runs in constant velocity mode.
2. TILT : Turn on/off the tilt servo.
3. Focus : Focus searching is executed and focus is turned on.
Operation is terminated if focus is not turned on after
focus search is retried about 3 times.
4. Track : Turn on/off the tracking servo.
5. Sled : Turn on/off the sled servo.
6. AGC : Turns on/off the focus error auto gain control by PULL
IN level. (DVD only)
7. CLVA : Spindle normal servo.
8. CAV : Spindle in constant velocity mode
9. Home : Return to home position.
→. Sled FWD: Move the sled system outside.
Perform this with the tracking turned off.
←. Sled RVS : Move the sled system inside.
Perform this with the tracking turned off.
↑ . Tilt Up : Move the tilt system up.
↓ . Tilt Down : Move the tilt system down.
6-6. Drive Manual Operation
In performing manual operation, observe the following points:
Select correct disc type on the Disc Type screen.
First, select “0. Disc Type” and execute “7. Hydet init” and “8.
Sled init”. (See Figure 12)
In case of abnormality, press [STOP] immediately to stop opera-
tion and turn off the power.
Do not execute Auto Adjust while executing FG Pause.
Also, as these commands are not protected, take care not to press
wrong key.
When PLL is locked, the sector address (or time code) is displayed
on the right side of SA.
6-6-1. Drive Manual Operation Menu Screen
Drive Manual Operation
SA.000000 SI.00 EMG.00
0. Disc Type
1. Manual Control 1
2. Manual Control 2
3. Manual Control 3
4. Manual Adjust 1
5. Manual Adjust 2
6. Auto Adjust
7. Check
Figure 11
This screen provides a menu for manual operation, and you can go
directly to each screen from here. To return to this screen from
each screen, press the RETURN key.
If [SET UP] button is pressed, the screen returns to the Test Mode
menu.
For switching between respective screens, use the [CLEAR] key.
6-6-2. Disc Type
Disk type
SA.000000 SI.00 EMG.00
0. DVD SL 12cm 9. Home
1. CD 12cm
2. DVD DL 12cm
3. DVD SL 8cm
4. CD 8cm
5. DVD DL 8cm
6. Disc type check
7. Hydet init
8. Sled init.
DVD SL 12cm
Figure 12
On this screen, select the type of disc used.
“6. Disc type check” judges the disc loaded. Confirm that judg-
ment result meets the loaded disc type.
Judgment may fail if adjustment is not made yet immediately af-
ter EEPROM (IC801) Default Set. The CD which is not cut up to
the CD detection sensor position is judged as DVD. The optical
system will be damaged if other disc is loaded after selecting DVD
DL.
Be sure to set the disc type.
