Sony DVP-S7700 Service Manual

DVP-S7700
4-7 4-8
There are few cases that the part isn't mounted in this model is printed on this diagram.
TK-47 BOARD (SIDE A)
CN001 D-3
CN002 H-2
CN004 G-1
CN005 B-4
CN008 B-3
D003 C-4
D004 E-2
D006 F-5
IC004 C-4
IC005 D-4
IC006 F-3
IC011 E-5
Q001 E-2
Q004 E-2
Q005 E-2
Q007 D-4
Q008 F-3
Q009 F-3
Q010 D-3
4-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
TK-47 (RF, SERVO) PRINTED WIRING BOARD
– Ref. No.: TK-47 board; 3,000 series –
RF/SERVO
TK-47
POWER BLOCK
(HS-930SH)
(SWITCHING REGULATOR)
MB-84
(SIGNAL PROCESS/
SERVO)
HP-120
(HEAD PHONE)
PW-120
(IR/POWER SWITCH)
FR-160
(FUNCTION SWITCH)
DC MOTOR
(SPINDLE)
DR-88
(DOOR SENSOR)
CN-113
(DOOR MOTOR)
TK-47
(RF/SERVO)
YS-19
(COMPONENT
VIDEO)
AU-218
(AUDIO)
FG-43
(SLED)
PS-421
(AUDIO POWER)
FP-75
(FL DRIVER)
FL-108
(FUNCTION SWITCH)
ER-8 (AEP, UK)
(EURO AV)
1-669-298-
05
(13)
13
TK-47 BOARD(SIDE A)
A
B
C
D
E
F
G
H
123456
48
33
32
17
16
1
64
49
48
25
32
1
8
9
16
17
24

Sony DVP-S7700 Specifications

General

Type	DVD player
Video Output	Composite, S-Video, Component
Digital Output	Coaxial, Optical
Signal-to-Noise Ratio	115 dB
Audio Format	Dolby Digital, DTS
Disc formats	CD, CD-R, CD-RW
Output Resolution	480p
Audio Output	Stereo
Output Level	2.0 Vrms
Dimensions	430 x 98 x 360 mm
DAC	24-bit/96kHz
Channels	2
