[5] How to Use Before use Parts and controls
Parts and controls (back/bottom)
1. Viewfinder （FDR-AX33/AXP33/AXP35）
This product is turned on when the viewfinder is pulled out.
2. Viewfinder lens adjustment dial (FDR-AX33/AXP33/AXP35)
If the indications in the viewfinder appear blurred, adjust the viewfinder lens adjustment
dial.
3. START/STOP button
4. POWER/CHG (charge) lamp
5. Built-in USB Cable
6. DC IN jack
7. Tripod receptacle
Attach a tripod (sold separately: the length of the screw must be less than 5.5 mm (7/32
in.)). Depending on the specifications of the tripod, this product may not attach in the
proper direction.
8. BATT (battery) release lever
9. Battery pack
To fasten the grip belt
