13
GB
GB
9 ID MODE (ON/0-9/SET/C/OFF) buttons
You can operate a specific display without affecting other displays
installed at the same time.
• ON button: Press to show the “Index Number” on the screen.
• 0-9 button: Press to enter the “Index Number” of the display you want
to operate.
• SET button: Press to set the input “Index Number”.
• C button: Press to clear the input “Index Number”.
• OFF button: Press to return to the normal mode.
See page 16.
0 +/– button
Adjusts the picture (contrast) level.
qa +/– button
Press to adjust the volume.
qs button
Press to mute the sound. Press again to restore sound.
qd ECO button
Press to reduce the power consumption by adjusting the backlight
brightness. This also enhances the black level. Select from “Off”,
“Low”, “High” or “Picture Off”. See page 16.
qf DISPLAY button
Press to display the currently selected input, the type of the input
signal and the “Wide Mode” setting on the screen. Press again to hide
them. If this displayed information is left undisturbed for a short time,
it will disappear automatically.
qg OPTION 1/OPTION 2 button
When an optional adaptor is installed, selects an input signal from the
equipment connected to the optional adaptor. Press the OPTION 1
button to select the input signal of the OPTION 1 connector, and
press the OPTION 2 button to select the input signal of the OPTION
2 connector.
qh HD15 button
Press to select the input signal of the HD15 connector. The RGB
signal or component signal is selected automatically in accordance
with the connected equipment.
qj STANDBY button
Press to change the display to the standby mode.
HDMI2
ON
STANDBY
HD15
ON
ID MODE
OFF
SET
OPTION1
DISPLAY
ECO
SOUND
OPTION2
HDMI1
RM-FW001
