33
GB
GB
Input Signal Reference
Chart
a) VGA is a registered trademark of International Business
Machines Corporation, U.S.A.
b) VESA is a registered trademark of the Video Electronics
Standards Association.
c) Mac (Macintosh) is a registered trademark of Apple
Computer, Inc.
• For HDTV signals, input the tri-level sync signal to the
2nd pin of RGB/COMPONENT (D-sub 15 pin) on the
HD15 connector or the BKM-FW12 (optional adaptor).
• If colors appear too light after input of a DVD signal to the
display, adjust “Color” in the “Picture” settings.
• When the phase is readjusted, the resolution will be
reduced.
Actual on-screen display of the input signal
and the display’s status
PC signals
Resolution
horizontal
frequency
(kHz)
vertical
frequency
(Hz)
1VGA
a)
-1 (VGA 350) 31.5 70
2
640 × 480@60 Hz
(VESA
b)
STD)
31.5 60
3Mac
c)
13" 35.0 67
4 VGA (VGA TEXT) 31.5 70
5
800 × 600@60 Hz (VESA STD) 37.9 60
6 Mac 16" 49.7 75
7
1024 × 768@60 Hz
(VESA STD)
48.4 60
8
1024 × 768@75 Hz
(VESA STD)
60.0 75
9
1024 × 768@85 Hz
(VESA STD)
68.7 85
10
1280 × 1024@60 Hz
(VESA STD)
64.0 60
11
848 × 480@60 Hz (VESA STD) 29.8 60
12
848 × 480@60 Hz (VESA STD) 29.5 60
13 848 × 480@75 Hz 37.7 75
14 1280 × 768@60 Hz 47.8 60
15 1280 × 768@60 Hz 47.4 60
16 1360 × 768@60 Hz 47.7 60
17 1360 × 768@60 Hz 47.4 60
TV/Video signals
Resolution
Available Inputs
Video Component/
RGB
HDMI
1 480/60i aa a
2 480/60p aa
3 575/50i aa a
4 576/50p
aa
5 720/50p
aa
6 720/60p
aa
7 1080/50i
aa
8 1080/60i
aa
9 1080/50p
a
10 1080/60p
a
Notes
On-screen
display
Significance
640 × 480 / 60 (e.g.) The selected input signal is a PC
signal.
480 / 60I (e.g.) The selected input signal is
component video.
NTSC (e.g.) The selected input signal is
NTSC.
Not Supported Signal The selected input signal is
non-supported signal.
No Signal There is no input signal.
HD15 The selected input signal is
HD15.
HDMI 1 The selected input signal is
HDMI 1.
HDMI 2 The selected input signal is
HDMI 2.
Option 1 The selected input signal is
OPTION 1.
Option 2 The selected input signal is
OPTION 2.
