Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
82
C3404 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3405 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3406 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3409 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3410 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3411 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3412 1-114-885-51 FILM 1uF 5% 50V
C3413 1-112-246-11 ELECT 100uF 20% 35V
C3414 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3415 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3551 1-115-871-11 ELECT 1uF 20% 50V
C3552 1-126-964-11 ELECT 10uF 20% 50V
C3553 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3556 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3561 1-126-947-11 ELECT 47uF 20% 35V
C3901 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3902 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3903 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3904 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3905 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3906 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3908 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3911 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3912 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3913 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3914 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3915 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3916 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3917 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3918 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN306 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P (DZ810)
CN472 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN503 1-820-116-41 CONNECTOR, FFC/FPC 17P
(DZ170/DZ171/DZ175)
CN504 1-820-117-41 CONNECTOR, FFC/FPC 19P
(DZ310/DZ510/DZ610/DZ810)
CN506 1-820-115-41 CONNECTOR, FFC/FPC 15P
(DZ310/DZ510/DZ610/DZ810)
CN507 1-785-468-41 CONNECTOR, FFC/FPC 13P
(DZ170/DZ171/DZ175)
CN508 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN510 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN1105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN1501 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN1502 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
CN1701 (Not supplied) CONNECTOR, HDMI 19P (HDMI OUT)
(DZ170/DZ171/DZ175)
CN1701 (Not supplied) CONNECTOR, HDMI 19P (HDMI OUT (ARC))
(DZ310/DZ510/DZ610/DZ810)
CN2101 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN3000 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D502 6-501-817-01 DIODE MA2J1110GLS0
D503 6-501-817-01 DIODE MA2J1110GLS0
D505 6-501-817-01 DIODE MA2J1110GLS0
D2101 6-501-749-01 DIODE MAZ8082G0LS0
D2102 6-501-592-01 DIODE EDZCTE616.8B
D2103 6-501-592-01 DIODE EDZCTE616.8B
D3071 6-500-335-01 DIODE MC2838-T112-1
D3072 6-501-817-01 DIODE MA2J1110GLS0
D3101 6-501-696-01 DIODE RSA39LTE25
D3102 6-501-696-01 DIODE RSA39LTE25
D3151 6-501-696-01 DIODE RSA39LTE25
D3152 6-501-696-01 DIODE RSA39LTE25
D3201 6-501-696-01 DIODE RSA39LTE25
D3202 6-501-696-01 DIODE RSA39LTE25
D3251 6-501-696-01 DIODE RSA39LTE25
D3252 6-501-696-01 DIODE RSA39LTE25
D3301 6-501-696-01 DIODE RSA39LTE25
D3302 6-501-696-01 DIODE RSA39LTE25
D3401 6-501-696-01 DIODE RSA39LTE25
D3402 6-501-696-01 DIODE RSA39LTE25
D3551 6-500-848-01 DIODE MC2840-T112-1
D9712 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB472 1-469-094-21 FERRITE, EMI (SMD) (1608) (DZ810)
FB473 1-469-094-21 FERRITE, EMI (SMD) (1608) (DZ810)
* FB1106 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1107 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1108 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1109 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1111 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1112 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1113 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1115 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1116 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1117 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1118 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB2101 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB2103 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
< IC >
IC303 6-710-554-01 IC PCM1808PWR
IC304 8-759-825-15
IC LC89056W-E
IC307 8-759-680-48 IC TC7WH157FK(TE85R)
IC471 6-707-853-01 IC TC74LCX541FT(EKJ)
IC501 6-706-492-01 IC TC7SHU04FU(T5RSOJF)
(DZ170/DZ171/DZ175)
IC502 6-600-466-01 IC TORX147L(SONY)
(TV/CABLE (DIGITAL IN OPTICAL))
(DZ170/DZ171/DZ175)
IC502 6-600-466-01 IC TORX147L(SONY) (TV (DIGITAL IN OPTICAL))
(DZ510/DZ610/DZ810)
IC503 A-1748-165-A IC R5F364AEDFA (for SERVICE)
IC504 6-705-338-01 IC TK11250CMCL-G
IC506 6-705-203-01 IC S-80935CNMC-G85T2G
IC507 (Not supplied) IC MM1665AHBE
IC509 6-712-613-01 IC SI-3010KM-TLS
IC510 6-709-584-01 IC MM1663DHBE
MAIN
Note: When IC507 on the Main board is damaged, exchange the
new Main board for the Main board which IC damaged.
To Next Page
