Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
8383
IC701 6-709-888-01 IC TC7WHU04FK(T5RSOYF
(DZ310/DZ510/DZ610/DZ810)
IC1101 6-714-722-01 IC CXD9927R-B (DZ170/DZ171/DZ175)
IC1101 6-714-723-01 IC CXD9917R-B (DZ310/DZ510/DZ610/DZ810)
IC1102 6-715-100-01 IC MX29LV320DBTI-70-OHI-1001UC
(US,CND,E32)
IC1102 6-715-101-01 IC MX29LV320DBTI-70-OHI-1001CE
(E3,E12,E15,EA)
IC1102 6-715-102-01 IC MX29LV320DBTI-70-OHI-1001GA (SP)
IC1103 (Not supplied) IC BR24S64F-WE2
IC1104 6-714-642-01 IC EM638165 TSA-6G
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1110 6-707-739-01 IC MM1661JTRE
IC1501 (Not supplied) IC BD8203EFV-E2
IC1601 6-713-555-01 IC MFI341S2161 (DZ170/DZ171/DZ175)
IC1705 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1707 6-705-337-01 IC TK11150CSCL-G
IC1708 6-702-302-01 IC TK11133CSCL-G
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-714-743-01 IC MM3404A18URE
IC3051 6-706-492-01 IC TC7SHU04FU(T5RSOJF)
IC3100 6-714-477-01 IC CXD9981TN
IC3200 6-714-477-01 IC CXD9981TN
IC3300 6-714-477-01 IC CXD9981TN
< JACK >
J501 1-822-282-1
1 JACK, PIN 1P (TV/CABLE (DIGITAL IN COAXIAL))
(DZ170/DZ171/DZ175)
< COIL >
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
L303 1-469-525-91 INDUCTOR 10uH
L471 1-469-527-91 INDUCTOR 47uH
L501 1-469-525-91 INDUCTOR 10uH (EXCEPT DZ310)
L502 1-469-525-91 INDUCTOR 10uH (DZ170/DZ171/DZ175)
L1701 1-457-374-21 COIL, COMMON MODE CHOKE
L1702 1-457-374-21 COIL, COMMON MODE CHOKE
L1703 1-457-374-21 COIL, COMMON MODE CHOKE
L1704 1-457-374-21 COIL, COMMON MODE CHOKE
L2101 1-457-374-21 COIL, COMMON MODE CHOKE
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-469-525-91 INDUCTOR 10uH
L3052 1-469-525-91 INDUCTOR 10uH
L3053 1-469-525-91 INDUCTOR 10uH
L3101 1-457-579-11 COIL, CHOKE 10uH
L3151 1-457-579-11 COIL, CHOKE 10uH
L3201 1-457-579-11 COIL, CHOKE 10uH
L3251 1-457-579-11 COIL, CHOKE 10uH
L3301 1-457-579-11 COIL, CHOKE 10uH
L3401 1-457-579-11 COIL, CHOKE 10uH
L3901 1-457-078-11 COIL, AIR-CORE
L3902 1-457-077-11 COIL, AIR-CORE
L3903 1-457-078-11 COIL, AIR-CORE
L3904 1-457-077-11 COIL, AIR-CORE
L3905 1-457-078-11 COIL, AIR-CORE
L3906 1-457-077-11 COIL, AIR-CORE
L3907 1-457-078-11 COIL, AIR-CORE
L3908 1-457-077-11 COIL, AIR-CORE
< TRANSISTOR >
Q501 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q502 6-551-272-01 TRANSISTOR RT3CLLM
Q1101 6-552-279-01 FET RT3K66M-T111-1
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q1701 6-552-279-01 FET RT3K66M-T111-1
Q2101 6-551-272-01 TRANSISTOR RT3CLLM
Q3000 8-729-111-29 TRANSISTOR 2SD1616A-K
Q3001 6-551-272-01 TRANSISTOR RT3CLLM
Q3101 6-551-271-01 TRANSISTOR RT3AMMM
Q3151 6-551-271-01 TRANSISTOR RT3AMMM
Q3201 6-551-271-01 TRANSISTOR RT3AMMM
Q3202 6-551-271-01 TRANSISTOR RT3AMMM
Q3301 6-551-271-01 TRANSISTOR RT3AMMM
Q3401 6-551-271-01 TRANSISTOR RT3AMMM
Q3551 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q3552 6-551-272-01 TRANSISTOR RT3CLLM
Q9730 6-551-714-01 FET INK0001AC1-T112A-1
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R306 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R309 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ810)
R316 1-216-801-11 METAL CHIP 22 5% 1/10W
R317 1-216-801-11 METAL CHIP 22 5% 1/10W
R318 1-216-801-11 METAL CHIP 22 5% 1/10W
R319 1-216-801-11 METAL CHIP 22 5% 1/10W
R329 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R330 1-216-839-11 METAL CHIP 33K 5% 1/10W
R331 1-216-805-11 METAL CHIP 47 5% 1/10W
R332 1-216-805-11 METAL CHIP 47 5% 1/10W
R333 1-216-864-11 SHORT CHIP 0
R334 1-216-809-11 METAL CHIP 100 5% 1/10W
R335 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R337 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ170/DZ171/DZ175)
R338 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ170/DZ171/DZ175)
R340 1-216-809-11 METAL CHIP 100 5% 1/10W
R341 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
MAIN
Note: When IC1103 and IC1501 on the Main board are damaged, exchange
the new Main board for the Main board which IC damaged.
