Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
8787
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3552 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3558 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R3561 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3562 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R3563 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R9941 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9942 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9945 1-216-813-11 METAL CHIP 220 5% 1/10W
R9946 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB1103 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1104 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1105 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1106 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1109 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1110 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1111 1-234-371-21 RES, NETWORK 47X4 (1005)
RB1112 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1113 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1114 1-234-370-21 RES, NETWORK 22X4 (1005)
RB1115 1-234-370-21 RES, NETWORK 22X4 (1005)
< TERMINAL BOARD >
TB3901 1-780-840-11 TERMINAL BOARD (SPEAKER) 4P (SPEAKERS
(FRONT R,FRONT L,SUBWOOFER,CENTER))
< VIBRATOR >
X301 1-814-382-11 QUARTZ CRYSTAL UNITS (24.576MHz)
X501 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1101 1-814-381-11 QUARTZ CRYSTAL UNITS (27MHz)
X3051 1-814-266-11 VIBRATOR, CRYSTAL (49.152MHz)
*************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK/TRAY DETECT)
*************************************************************
A-1746-219-A P-SW BOARD, COMPLETE
*********************
< CAPACITOR >
C5301 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN5301 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< SWITCH >
S5301 1-786-650-21 SWITCH, TACTILE ("/1)
*************************************************************
A-1745-461-A POWER BOARD, COMPLETE
(DZ310:E3,E12,SP/DZ510/DZ610)
A-1745-463-A POWER BOARD, COMPLETE
(DZ170/DZ171/DZ175)
A-1745-467-A POWER BOARD, COMPLETE (DZ310:E32)
A-1761-521-A POWER BOARD, COMPLETE
(DZ810:E3,E12,SP,E15,EA)
A-1761-527-A POWER BOARD, COMPLETE (DZ810:E32)
***********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C901 1-114-594-11 FILM 0.22uF 10% 310V
0 C902 1-114-594-11 FILM 0.22uF 10% 310V
(E3,E12,SP,E15,EA)
0 C902 1-116-397-21 FILM 0.33uF 10% 310V
(US,CND,E32)
0 C903 1-114-345-21 ELECT(BLOCK) 1000uF 20% 200V
(DZ170/DZ171/DZ175)
0 C903 1-114-347-21 ELECT(BLOCK) 330uF 20% 450V
(DZ310/DZ510/DZ610/DZ810)
0 C905 1-116-392-11 FILM 0.01uF 5% 400V
(DZ170/DZ171/DZ175)
0 C905 1-116-393-11 FILM 0.0033uF 5% 400V
(DZ310/DZ510/DZ610/DZ810)
0 C906 1-117-815-11 FILM 0.001uF 3% 1.5KV
(DZ310/DZ510/DZ610/DZ810)
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(DZ310/DZ510/DZ610/DZ810)
C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(DZ170/DZ171/DZ175)
C908 1-107-909-11 ELECT 47uF 20% 50V
C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C910 1-126-965-91 ELECT 22uF 20% 50V
(EXCEPT E32)
C910 1-126-967-11 ELECT 47uF 20% 50V
(E32)
C916 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
0 C918 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C920 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C921 1-117-220-81 CERAMIC 150PF 5% 2KV
C922 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C923 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
0 C924 1-116-393-11 FILM 0.0033uF 5% 400V
C925 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C926 1-107-930-91 ELECT 22uF 20% 100V
C927 1-112-223-11 ELECT 3300uF 20% 10V
C928 1-112-232-11 ELECT 2700uF 20% 16V
C929 1-112-241-21 ELECT 1000uF 20% 25V
C932 1-114-994-11 ELECT 2200uF 20% 35V
C933 1-114-994-11 ELECT 2200uF 20% 35V
C934 1-112-831-31 ELECT 2200uF 20% 35V
C935 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C936 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
0 C938 1-112-869-51 CERAMIC 470PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-112-228-21 ELECT 1000uF 20% 16V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-935-11 ELECT 470uF 20% 16V
C950 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
MAIN MS-203 P-SW POWER
