Sony HBD-DZ310 - Page 88

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
88
0 C963 1-112-869-51 CERAMIC 470PF 10% 250V
(DZ310/DZ510/DZ610/DZ810)
0 C963 1-112-870-51 CERAMIC 0.001uF 20% 250V
(DZ170/DZ171/DZ175)
0 C964 1-112-869-51 CERAMIC 470PF 10% 250V
(DZ310/DZ510/DZ610/DZ810)
0 C964 1-112-870-51 CERAMIC 0.001uF 20% 250V
(DZ170/DZ171/DZ175)
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C972 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C973 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C975 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
0 C980 1-117-828-11 FILM 0.0033uF 3% 1.5KV
(DZ170/DZ171/DZ175)
C981 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C983 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C984 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C987 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(DZ810)
C990 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C991 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C992 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C993 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C994 1-112-869-51 CERAMIC 470PF 10% 250V
(DZ310/DZ510/DZ610)
C997 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C998 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN904 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
* CN906 1-764-334-11 PLUG, CONNECTOR 11P
CN908 1-564-505-11 PLUG, CONNECTOR 2P (DZ810)
< DIODE >
D901 8-719-082-57 DIODE D5SBA60F01
D902 8-719-063-74 DIODE D1NL20U-TR2
D906 6-501-817-01 DIODE MA2J1110GLS0
D907 6-501-817-01 DIODE MA2J1110GLS0
D908 6-501-817-01 DIODE MA2J1110GLS0
D909 6-501-817-01 DIODE MA2J1110GLS0
D910 6-501-817-01 DIODE MA2J1110GLS0
D913 6-500-241-01 DIODE SARS03
D914 6-501-817-01 DIODE MA2J1110GLS0
D931 6-501-849-01 DIODE FMX-22SL
D942 6-502-518-01 DIODE 50PQSA065-FA9
D943 8-719-080-53 DIODE RK36LF-B3
D946 6-502-234-01 DIODE EG01C LF-F7 (DZ810)
D946 8-719-030-25 DIODE EG01CV0 (EXCEPT DZ810)
D954 6-500-288-11 DIODE EK19LF-F7 (DZ810)
D954 8-719-080-59 DIODE EK19-V0 (EXCEPT DZ810)
D955 6-500-288-11 DIODE EK19LF-F7 (DZ810)
D955 8-719-080-59 DIODE EK19-V0 (EXCEPT DZ810)
DZ901 6-501-782-01 DIODE MAZ8180GMLS0
DZ902 6-502-231-01 DIODE MAZ8220GLLSO
DZ903 6-501-787-01 DIODE MAZ8220GMLS0
DZ905 6-501-792-01 DIODE MAZ8300GMLS0
(DZ310/DZ510/DZ610/DZ810)
DZ905 8-719-083-71 DIODE UDZSUSTE-1730B (DZ170/DZ171/DZ175)
DZ915 6-501-760-01 DIODE MAZ8100GMLS0
DZ951 8-719-083-71 DIODE UDZSUSTE-1730B
DZ954 8-719-083-71 DIODE UDZSUSTE-1730B
(DZ310/DZ510/DZ610/DZ810)
< FUSE >
0 F945 1-576-794-11 FUSE, MICRO (1608) 2A
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< RESISTOR >
0 FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0
IC901 6-707-741-01 IC STR-F6138-LF1352 (DZ170/DZ171/DZ175)
0
IC901 6-707-742-01 IC STR-F6168-LF1352
(DZ310/DZ510/DZ610/DZ810)
IC921 (Not supplied) IC STR-Y6763
IC923 6-711-947-01 IC MM1431CURE
IC932 6-711-947-01 IC MM1431CURE
IC941 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L931 1-457-878-65 COIL, CHOKE 2.2uH
L954 1-457-578-11 COIL, CHOKE 10uH
L956 1-457-578-11 COIL, CHOKE 10uH
L963 1-469-525-91 INDUCTOR 10uH
L964 1-457-725-11 COIL, CHOKE 4.7uH
L967 1-457-725-11 COIL, CHOKE 4.7uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER (E3,E12,SP,E15,EA)
0 LF901 1-457-449-11 COIL, LINE FILTER (US,CND,E32)
0 LF902 1-457-054-21 COIL, LINE FILTER (E3,E12,SP,E15,EA)
0 LF902 1-457-449-11 COIL, LINE FILTER (US,CND,E32)
< PHOTO COUPLER >
0 PC901 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC902 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
Q901 8-729-201-53 TRANSISTOR 2SA1015-GR
Q922 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q943 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q945 6-552-458-01 FET 2SK3577
Q949 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q950 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q969 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W F
(DZ170/DZ171/DZ175)
0 R901 1-240-938-91 METAL 1.5M 5% 1/2W F
(DZ310/DZ510/DZ610/DZ810)
0 R903 1-250-297-65 METAL OXIDE 100K 5% 3W F
(DZ310/DZ510/DZ610/DZ810)
0 R903 1-250-299-65 METAL OXIDE 33K 5% 3W F
(DZ170/DZ171/DZ175)
POWER
Note: When IC921 on the Power board is damaged, exchange the
new Power board for the Power board which IC damaged.
