Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
8989
0 R904 1-250-297-65 METAL OXIDE 100K 5% 3W F
(DZ310/DZ510/DZ610/DZ810)
0 R904 1-250-299-65 METAL OXIDE 33K 5% 3W F
(DZ170/DZ171/DZ175)
R905 1-216-797-11 METAL CHIP 10 5% 1/10W
R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R912 1-216-363-00 METAL OXIDE 0.33 5% 2W F
(DZ310/DZ510/DZ610/DZ810)
0 R914 1-220-891-11 METAL 0.1 10% 5W F
(DZ310/DZ510/DZ610/DZ810)
0 R914 1-248-180-11 METAL 0.034 5% 5W F
(DZ170/DZ171/DZ175)
0 R916 1-250-297-65 METAL OXIDE 100K 5% 3W F
R917 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R919 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R922 1-250-262-41 METAL 0.39 5% 2W F
R923 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R925 1-216-797-11 METAL CHIP 10 5% 1/10W
R926 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R931 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R932 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R933 1-216-821-11 METAL CHIP 1K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R938 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R939 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R940 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R941 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R942 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R945 1-216-837-11 METAL CHIP 22K 5% 1/10W
R946 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R949 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R951 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R952 1-216-864-11 SHORT CHIP 0
R954 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R956 1-216-817-11 METAL CHIP 470 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R959 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R962 1-216-864-11 SHORT CHIP 0
R963 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R965 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
R972 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R974 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R976 1-216-833-11 METAL CHIP 10K 5% 1/10W
R978 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R992 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R998 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R999 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
< TRANSFORMER >
0 T901 1-443-649-11 TRANSFORMER, CONVERTER
(DZ170/DZ171/DZ175)
0 T901 1-443-874-11 TRANSFORMER, CONVERTER
(DZ310/DZ510/DZ610/DZ810)
0 T903 1-445-320-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-841-21 THERMISTOR, NTC 3.0 (US,CND,E32)
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0 (E3,E12,SP,E15,EA)
< VARISTOR >
0 VDR901 1-802-839-11 VARISTOR
*************************************************************
S-AIR CON BOARD (DZ810)
***************
< CONNECTOR >
CN100 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN102 1-564-517-11 PLUG, CONNECTOR 2P
CN103 1-821-744-11 CONNECTOR, CARD EDGE 30P (EZW-T100)
< TRANSISTOR >
Q100 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q101 6-550-363-01 TRANSISTOR 2SB1690KT146
< RESISTOR >
R100 1-216-817-11 METAL CHIP 470 5% 1/10W
R101 1-216-817-11 METAL CHIP 470 5% 1/10W
R102 1-216-817-11 METAL CHIP 470 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C5401 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C5402 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C5403 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C5404 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C5405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5406 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5407 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5408 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN5401 1-564-519-11 PLUG, CONNECTOR 4P
< COIL >
L5401 1-457-077-11 COIL, AIR-CORE
L5402 1-457-078-11 COIL, AIR-CORE
L5403 1-457-077-11 COIL, AIR-CORE
L5404 1-457-078-11 COIL, AIR-CORE
POWER S-AIR CON SPEAKER
