Sony HBD-DZ310 - Page 90

Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
90
< TERMINAL BOARD >
TB5401 1-780-452-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKERS (SUR R,SUR L))
*************************************************************
USB BOARD
**********
< CAPACITOR >
C5501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-822-423-11 CONNECTOR, USB (A) 4P (USB)
CN5502 1-784-922-11 PIN, CONNECTOR 5P
*************************************************************
MISCELLANEOUS
**************
102 1-832-579-21 CABLE, FLEXIBLE FLAT (13 CORE)
(DZ170/DZ171/DZ175)
102 1-832-589-21 CABLE, FLEXIBLE FLAT (15 CORE)
(DZ310/DZ510/DZ610/DZ810)
152 1-832-576-21 CABLE, FLEXIBLE FLAT (13 CORE) (DZ810)
153 1-832-813-21 CABLE, FLEXIBLE FLAT (9 CORE)
0 156 1-834-966-41 CORD, POWER-SUPPLY
(DZ310/DZ510/DZ610/DZ810)
0 156 1-837-308-11 CORD, POWER-SUPPLY (DZ170/DZ171/DZ175)
0 157 1-770-019-71 ADAPTOR, CONVERSION PLUG 3P (EA)
0 158 1-569-008-33 ADAPTOR, CONVERSION (E32)
203 1-832-538-21 CABLE, FLEXIBLE FLAT (5 CORE)
206 1-832-553-21 CABLE, FLEXIBLE FLAT (9 CORE)
207 1-832-592-21 CABLE, FLEXIBLE FLAT (17 CORE)
(DZ170/DZ171/DZ175)
207 1-832-602-21 CABLE, FLEXIBLE FLAT (19 CORE)
(DZ310/DZ510/DZ610/DZ810)
0 257 8-820-321-12 OPTICAL PICK-UP (KHM-313CAA/C2RP1)
258 1-828-773-51 WIRE (FLAT TYPE) (24 CORE)
0 F901 1-533-311-12 FUSE, GLASS (DIA. 5) (8A/125V) (US,CND)
0 F901 1-576-232-51 FUSE (H.B.C.) (5A/250V) (E3,E12,SP,E15,EA)
0 F901 1-576-233-51 FUSE (H.B.C.) (6.3A/250V) (E32)
FAN3001 1-787-396-21 FAN, DC (50 SQUARE)
TU901 1-693-780-11 TUNER (FM) (DZ310/DZ510/DZ610/DZ810)
TU901 1-693-781-11 TUNER (FM) (DZ170/DZ171/DZ175)
SPEAKER USB
