Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
64
S620 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S621 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S623 1-762-875-21 SWITCH, KEYBOARD (– .)
S624 1-762-875-21 SWITCH, KEYBOARD (x)
S625 1-762-875-21 SWITCH, KEYBOARD (gG)
S626 1-762-875-21 SWITCH, KEYBOARD (S)
S627 1-762-875-21 SWITCH, KEYBOARD (> +)
S628 1-762-875-21 SWITCH, KEYBOARD (TUNER)
S629 1-762-875-21 SWITCH, KEYBOARD (CD)
S630 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S631 1-762-875-21 SWITCH, KEYBOARD (MD(VIDEO))
S632 1-762-875-21 SWITCH, KEYBOARD (DOWN)
S633 1-762-875-21 SWITCH, KEYBOARD (UP)
S637 1-762-875-21 SWITCH, KEYBOARD (POWER)
S638 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S639 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S640 1-762-875-21 SWITCH, KEYBOARD (LEFT)
S641 1-762-875-21 SWITCH, KEYBOARD (RIGHT)
S642 1-762-875-21 SWITCH, KEYBOARD (DISK SKIP)
S643 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S644 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S645 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S646 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE)
S647 1-762-875-21 SWITCH, KEYBOARD (KARAOKE)
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC(12.5 MHz)
**************************************************************
1-678-153-11 SENSOR BOARD
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
*************
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
**************************************************************
A-4428-044-A SUB-TRANS BOARD, COMPLETE
(AED,AEP,G,UK,CIS)
**************************
A-4428-058-A SUB-TRANS BOARD, COMPLETE (US,CND)
**************************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C972 1-126-768-11 ELECT 2200uF 20.00% 16V
C973 1-126-933-11 ELECT 100uF 20.00% 16V
< CONNECTOR >
CN974 1-564-321-00 PIN, CONNECTOR 2P
* CN975 1-564-321-21 PIN, CONNECTOR 2P
CN976 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
< DIODE >
0D971 8-719-911-19 DIODE 1SS133T-72
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC971 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q971 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R975 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY971 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T972 1-435-209-11 TRANSFORMER, POWER (US,CND)
0T972 1-435-210-11 TRANSFORMER, POWER (AED,AEP,CIS,G,UK)
**************************************************************
A-4428-045-A TRANS BOARD, COMPLETE
(AED,AEP,G,UK,CIS)
**********************
A-4428-059-A TRANS BOARD, COMPLETE (US)
**********************
A-4428-069-A TRANS BOARD, COMPLETE
(AR,E,EA,MY,SP,TW)
**********************
A-4428-254-A TRANS BOARD, COMPLETE (CND)
**********************
A-4428-255-A TRANS BOARD, COMPLETE (AUS)
**********************
A-4428-261-A TRANS BOARD, COMPLETE (KR)
**********************
A-4428-264-A TRANS BOARD, COMPLETE (MX)
**********************
A-4428-597-A TRANS BOARD, COMPLETE (TH)
**********************
1-533-217-31 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C975 1-164-159-11 CERAMIC 0.1uF 50V
C976 1-126-969-11 ELECT 220uF 20.00% 50V
C978 1-126-964-11 ELECT 10uF 20.00% 50V
C979 1-126-968-11 ELECT 100uF 20.00% 50V
C980 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN971 1-564-321-00 PIN, CONNECTOR 2P
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
* CN972 1-564-526-11 PLUG, CONNECTOR 11P
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
* CN972 1-564-528-11 PLUG, CONNECTOR 13P
(AED,AEP,CIS,CND,G,UK,US)
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
D978 8-719-983-99 DIODE MTZJ-T-72-39D
D979 8-719-110-31 DIODE MTZJ-T-72-12B
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
