Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
65
< FUSE >
0F971 1-533-451-11 FUSE, GLASS TUBE (DIA. 5)(3.15A 125V)(CND)
0F971 1-533-452-11 FUSE, GLASS TUBE (DIA. 5)(4A 125V)(US)
0F971 1-533-466-11 FUSE, GLASS TUBE (DIA. 5)(1.25A 250V)
(AED,AEP,CIS,G,UK)
0F971 1-533-471-11 FUSE, GLASS TUBE (DIA. 5)(4A 250V)
(AR,E,EA,MX,MY,SP,TW)
0F972 1-533-469-11 FUSE, GLASS TUBE (DIA. 5)(2.5A 250V)
(AR,E,EA,KR,MY,SP,TH,TW)
0F973 1-533-468-11 FUSE, GLASS TUBE (DIA. 5)(2A 250)
(AR,AUS,E,EA,MY,SP,TW)
< TRANSISTOR >
Q972 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
0R971 1-219-122-91 FUSIBLE 0.33 5% 1/4W
0R972 1-219-119-81 FUSIBLE 0.1 5% 1/4W
R976 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
0R977 1-217-637-00 FUSIBLE 1 5% 1/4W
R978 1-249-429-11 CARBON 10K 5% 1/4W
R979 1-249-417-11 CARBON 1K 5% 1/4W F
R980 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
0S971 1-771-291-11 SWITCH, POWER (VOL SEL)
(AR,E,EA,MY,SP,TW)
< TRANSFORMER >
0T971 1-435-205-11 TRANSFORMER, POWER (US)
0T971 1-435-206-11 TRANSFORMER, POWER (CND)
0T971 1-435-207-11 TRANSFORMER, POWER (AED,AEP,CIS,G,UK)
0T971 1-435-208-11 TRANSFORMER, POWER
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
**************************************************************
MISCELLANEOUS
**************
M961 1-698-792-11 FAN, DC (AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
101 1-773-042-11 WIRE (FLAT TYPE) (17 CORE)
104 1-791-897-11 WIRE (FLAT TYPE) (19 CORE)
0108 1-690-608-11 CORD, POWER (AUS)
0108 1-769-079-21 CORD, POWER (KR)
0108 1-777-071-51 CORD, POWER
(AED,AEP,CIS,G,UK,EA,MY,SP,TW)
0108 1-783-532-11 CORD, POWER (CND,US)
0108 1-783-820-11 CORD, POWER (CND,US)
0108 1-783-941-21 CORD, POWER (AR)
0108 1-791-901-11 CORD, POWER (E,MX,TH)
0109 1-569-008-21 ADAPTOR, CONVERSION 2P(EA,MY,SP,TW)
0109 1-569-008-31 ADAPTOR, CONVERSION (EA,MY,SP,TW)
0110 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (CIS,UK)
209 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
216 1-471-035-11 MAGNET ASSY
**************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-871-01 SCREW +BVTT 3X6 (S)
#6 7-685-872-09 SCREW +BVTT 3X8 (S)
#7 7-685-880-09 SCREW +BVTT 4X6 (S)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
