Sony HCD-CP33 - Circuit Boards Locations

HCD-CP33
3535
1 IC306 qa
2 IC306 qd
3.0Vp-p
30.5µsec
4.1Vp-p
62.5ns
• Waveforms
– MAIN Board –
7-1. CIRCUIT BOARDS LOCATION
POWER board
MAIN board
LCD board
CONTROL(A) board
CONTROL(B) board
1 IC101 1, 2 (I, J)
(PLAY mode)
2 IC101 4 (A) (PLAY mode)
3 IC101 8, 9 (E, F)
(PLAY mode)
0.46Vp-p
0.1Vp-p
0.06Vp-p
4 IC121 qh (OSCI)
5 IC121 wj (LRCK)
6 IC121 wk (XBCK)
7 IC121 wl (FS256)
8 IC121 o; (FS4)
3.1Vp-p
22.581MHz
3.2Vp-p
44.1kHz
3.8Vp-p
2.822MHz
3.8Vp-p
11.29MHz
3.2Vp-p
176.4kHz
– BD (1/2) SECTION –– BD (2/2) SECTION –
LOADING board
BD board
DIGITAL board
SW board
Note
CD block, tape deck block and
tuner pack are supplied with
the assembled block.
1 IC316 qd
2 IC202 8
3.4Vp-p
100nsec
3.6Vp-p
44.4nsec
– DIGITAL Board –
