7-7. Printed Wiring Board – BD Section –
• See page 35 for Circuit Boards Location.
Ref. No. Location
D101 A-1
D181 D-3
D183 D-3
IC103 B-1
IC123 D-2
IC171 D-1
Q102 B-1
Q103 B-1
Q104 B-1
• Semiconductor
Location
Ref. No. Location
IC101 A-3
IC121 C-3
IC124 C-3
IC152 B-1
IC181 C-1
IC192 D-1
Q101 B-3
Q162 B-3
Q163 B-3
Q181 C-1
Q182 C-2
• Semiconductor
Location
16
TO
DIGITAL
BOARD
(Page 48)
TO
DIGITAL
BOARD
(Page 48)
16
