Sony HCD-CP33 - Page 63

63
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-2. FRONT PANEL SECTION
supplied
with RV801
#1
#1
#1
#1
51
53
52
54
55
59
#3
57
58
62
63
56
63
not
supplied
60
64
65
not
supplied
51 4-228-281-01 KNOB(VOLUME)
52 4-227-282-01 KNOB(BASS)
53 X-4952-862-1 PANEL SUB ASSY, FRONT (AEP,UK,AED)
53 X-4952-863-1 PANEL SUB ASSY, FRONT
(US,CND,E,JE,AR,SP,MY,TH,TW,KR,HK,AUS)
54 X-4952-867-1 HOLDER SUB ASSY, CASSETTE
55 1-677-895-11 LCD BOARD
56 1-792-769-11 WIRE(FLAT TYP) (9 CORE)
57 4-217-319-01 PLATE, LCD LIGHT
58 4-218-204-01 FOOT(FRONT)
59 4-228-286-01 SPRING (OPEN CASSETTE)
60 3-351-377-11 GEAR, DAMPER
62 X-4949-669-2 LEVER (LOCK) ASSY
63 4-931-757-31 SCREW(DIA.2.6X8)(IT3B),TAPPING
64 A-4473-146-A CONTROL (A) BOARD, COMPLETE
65 A-4473-145-A CONTROL (B) BOARD, COMPLETE
Ver 1.2 2003.05
