Sony HCD-CPX22 - Page 64

64
HCD-CPX22/NXM3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D708 8-719-988-61 DIODE 1SS355TE-17
D709 8-719-988-61 DIODE 1SS355TE-17
D710 8-719-988-61 DIODE 1SS355TE-17
D711 8-719-988-61 DIODE 1SS355TE-17
D712 8-719-988-61 DIODE 1SS355TE-17
D755 6-500-260-01 DIODE P6SMB39AT3
D756 6-500-260-01 DIODE P6SMB39AT3
< EARTH TERMINAL >
EP701 1-537-738-21 TERMINAL, GROUND
EP702 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB702 1-216-864-11 SHORT CHIP 0
< FILTER >
FL702 1-234-177-21 FILTER, CHIP EMI
FL703 1-234-177-21 FILTER, CHIP EMI
FL704 1-234-177-21 FILTER, CHIP EMI
FL706 1-234-177-21 FILTER, CHIP EMI
< IC >
IC701 6-701-834-01 IC PCM1802DBR
IC703 8-759-387-77 IC TC7WU04F (TE12R)
IC704 6-700-263-01 IC NJM2870F18 (TE2)
IC705 6-705-979-01 IC CXD9788AR
IC706 8-759-583-47 IC uPC2933T-E2
IC707 6-705-695-01 IC CXD9775M
IC708 6-705-695-01 IC CXD9775M
IC709 6-701-189-01 IC MC74VHC1GU04DFT1
IC710 8-759-473-95 IC uPC2905T-E1
< COIL >
L701 1-412-951-11 INDUCTOR 10uH
L702 1-412-951-11 INDUCTOR 10uH
L703 1-412-951-11 INDUCTOR 10uH
L704 1-216-295-91 SHORT CHIP 0
L705 1-412-939-11 INDUCTOR 1uH
L708 1-456-813-11 COIL, AIR-CORE
L709 1-456-813-11 COIL, AIR-CORE
L710 1-456-680-11 COIL, CHOKE 10UF
L711 1-456-680-11 COIL, CHOKE 10UF
L712 1-412-951-11 INDUCTOR 10uH
L713 1-216-295-91 SHORT CHIP 0
L714 1-216-295-91 SHORT CHIP 0
L715 1-216-295-91 SHORT CHIP 0
L716 1-216-295-91 SHORT CHIP 0
L758 1-456-813-11 COIL, AIR-CORE
L759 1-456-813-11 COIL, AIR-CORE
L760 1-456-680-11 COIL, CHOKE 10UF
L761 1-456-680-11 COIL, CHOKE 10UF
< TRANSISTOR >
Q701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q702 8-729-602-36 TRANSISTOR 2SA1602-F
Q703 8-729-602-36 TRANSISTOR 2SA1602-F
Q752 8-729-602-36 TRANSISTOR 2SA1602-F
Q753 8-729-602-36 TRANSISTOR 2SA1602-F
< RESISTOR >
R701 1-216-864-11 SHORT CHIP 0
R704 1-216-864-11 SHORT CHIP 0
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-864-11 SHORT CHIP 0
R708 1-216-864-11 SHORT CHIP 0
R709 1-216-864-11 SHORT CHIP 0
R710 1-216-809-11 METAL CHIP 100 5% 1/10W
R711 1-216-809-11 METAL CHIP 100 5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
R713 1-216-837-11 METAL CHIP 22K 5% 1/10W
R714 1-216-818-11 METAL CHIP 560 5% 1/10W
R716 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R717 1-216-864-11 SHORT CHIP 0
R718 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R719 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R720 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R721 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R722 1-216-864-11 SHORT CHIP 0
R723 1-216-841-11 METAL CHIP 47K 5% 1/10W
R724 1-216-302-00 RES-CHIP 2.7 5% 1/10W
R725 1-216-302-00 RES-CHIP 2.7 5% 1/10W
R726 1-216-845-11 METAL CHIP 100K 5% 1/10W
R727 1-216-845-11 METAL CHIP 100K 5% 1/10W
R728 1-216-845-11 METAL CHIP 100K 5% 1/10W
R729 1-216-821-11 METAL CHIP 1K 5% 1/10W
R730 1-216-809-11 METAL CHIP 100 5% 1/10W
R731 1-216-809-11 METAL CHIP 100 5% 1/10W
R732 1-216-809-11 METAL CHIP 100 5% 1/10W
R735 1-216-864-11 SHORT CHIP 0
R736 1-216-857-11 METAL CHIP 1M 5% 1/10W
R737 1-216-821-11 METAL CHIP 1K 5% 1/10W
R739 1-216-864-11 SHORT CHIP 0
R741 1-216-809-11 METAL CHIP 100 5% 1/10W
R742 1-216-833-11 METAL CHIP 10K 5% 1/10W
R743 1-216-809-11 METAL CHIP 100 5% 1/10W
R744 1-216-864-11 SHORT CHIP 0
R745 1-216-809-11 METAL CHIP 100 5% 1/10W
R746 1-216-809-11 METAL CHIP 100 5% 1/10W
R747 1-216-809-11 METAL CHIP 100 5% 1/10W
R748 1-216-841-11 METAL CHIP 47K 5% 1/10W
R749 1-216-864-11 SHORT CHIP 0
R750 1-216-845-11 METAL CHIP 100K 5% 1/10W
R751 1-216-864-11 SHORT CHIP 0
R752 1-216-837-11 METAL CHIP 22K 5% 1/10W
R754 1-216-818-11 METAL CHIP 560 5% 1/10W
R756 1-216-809-11 METAL CHIP 100 5% 1/10W
R757 1-216-864-11 SHORT CHIP 0
R758 1-216-864-11 SHORT CHIP 0
R759 1-216-864-11 SHORT CHIP 0
R760 1-216-809-11 METAL CHIP 100 5% 1/10W
R761 1-216-809-11 METAL CHIP 100 5% 1/10W
R762 1-216-809-11 METAL CHIP 100 5% 1/10W
R764 1-216-864-11 SHORT CHIP 0
R766 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R767 1-216-864-11 SHORT CHIP 0
S-MASTER
