HCD-CPX22/NXM3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SP OUT
R768 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R769 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R770 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R771 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R772 1-216-864-11 SHORT CHIP 0
R773 1-216-841-11 METAL CHIP 47K 5% 1/10W
R774 1-216-302-00 RES-CHIP 2.7 5% 1/10W
R775 1-216-302-00 RES-CHIP 2.7 5% 1/10W
R776 1-216-845-11 METAL CHIP 100K 5% 1/10W
R777 1-216-845-11 METAL CHIP 100K 5% 1/10W
R778 1-216-845-11 METAL CHIP 100K 5% 1/10W
R779 1-216-864-11 SHORT CHIP 0
R781 1-216-809-11 METAL CHIP 100 5% 1/10W
R782 1-216-857-11 METAL CHIP 1M 5% 1/10W
R783 1-216-864-11 SHORT CHIP 0
R784 1-216-809-11 METAL CHIP 100 5% 1/10W
R785 1-216-809-11 METAL CHIP 100 5% 1/10W
R786 1-216-809-11 METAL CHIP 100 5% 1/10W
R787 1-216-809-11 METAL CHIP 100 5% 1/10W
R788 1-216-809-11 METAL CHIP 100 5% 1/10W
R789 1-216-809-11 METAL CHIP 100 5% 1/10W
R790 1-216-809-11 METAL CHIP 100 5% 1/10W
R792 1-216-864-11 SHORT CHIP 0
R793 1-216-845-11 METAL CHIP 100K 5% 1/10W
R795 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X701 1-795-843-11 VIBRATOR, CRYSTAL (12.288MHz)
X702 1-795-660-21 QUARTZ CRYSTAL UNIT (49.152MHz)
************************************************************
SP OUT BOARD
************
< CAPACITOR >
C591 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C592 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C594 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C595 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C596 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C597 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C598 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
C599 1-131-992-91 CERAMIC CHIP 100000PF 35V
(AEP, UK, EA, RU)
< CONNECTOR >
CN510 1-564-507-11 PLUG, CONNECTOR 4P
< EARTH TERMINAL >
EP505 1-537-738-21 TERMINAL, GROUND
< COIL >
L590 1-420-872-52 COIL, AIR-CORE (AEP, UK, EA, RU)
L591 1-420-872-52 COIL, AIR-CORE (AEP, UK, EA, RU)
L592 1-420-872-52 COIL, AIR-CORE (AEP, UK, EA, RU)
L593 1-420-872-52 COIL, AIR-CORE (AEP, UK, EA, RU)
< RESISTOR >
R592 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R593 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R594 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R595 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R596 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R597 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R598 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
R599 1-249-625-31 CARBON 10 5% 1/2W
(AEP, UK, EA, RU)
< TERMINAL >
TM504 1-537-114-21 TERMINAL BOARD (SPEAKER)
************************************************************
SW (1) BOARD
***********
< SWITCH >
S721 1-786-084-11 SWITCH, DETECTION (MAIN TRAY IN/OUT)
************************************************************
SW (2) BOARD
***********
< SWITCH >
S731 1-786-382-11 SWITCH, PUSH (1 KEY) (SUB TRAY IN)
************************************************************
A-4750-851-A VOL BOARD, COMPLETE
*******************
< CAPACITOR >
C1007 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1008 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1013 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN1050 1-784-776-11 CONNECTOR, FFC 15P
CN1051 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D1050 8-719-071-44 DIODE SELS5223C-TP15 (^/1)
D1051 8-719-988-61 DIODE 1SS355TE-17
