66
HCD-GN880
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
< IC >
IC1050 6-600-349-31 IC NJL24H400A
< TRANSISTOR >
Q1041 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1048 1-216-864-11 SHORT CHIP 0
R1049 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1050 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1059 1-216-805-11 METAL CHIP 47 5% 1/10W
R1090 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1091 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1092 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1093 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1094 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1095 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1042 1-762-875-21 SWITCH, KEYBOARD (^/1)
S1043 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S1050 1-786-418-11 SWITCH, ROTARY (ENCODER) (BASS)
S1051 1-786-418-11 SWITCH, ROTARY (ENCODER) (TREBLE)
S1052 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
************************************************************
MISCELLANEOUS
*************
3 1-769-972-11 WIRE (FLAT TYPE) (13 CORE)
4 1-765-332-11 WIRE (FLAT TYPE) (15 CORE)
5 1-769-869-11 WIRE (FLAT TYPE) (5 CORE)
6 1-769-939-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP, UK)
6 1-773-003-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
11 1-693-603-31 TUNER (FM/AM) (E3, E51, EA)
11 1-693-604-11 TUNER (FM/AM) (AEP, UK)
11 1-693-623-31 TUNER (FM/AM) (US)
11 1-693-654-11 TUNER (FM/AM) (RU)
59 1-796-880-11 DECK, MECHANISM
0102 1-468-813-11 REGULATOR, SWITCHING (AEP, UK, RU)
0102 1-468-819-11 REGULATOR, SWITCHING (US)
0102 1-468-821-11 REGULATOR, SWITCHING (E3, E51, EA)
0103 1-775-786-21 CORD, POWER (UK, EA)
0103 1-777-071-53 CORD, POWER (AEP, E51, RU)
0103 1-783-820-11 CORD, POWER (US)
0103 1-827-226-11 CORD, POWER (E3)
162 1-471-035-11 MAGNET ASSY
256 1-827-992-11 WIRE (FLAT TYPE) (16 CORE)
0259 8-820-244-01 OPTICAL PICK-UP (KSM-215DCP/C2NP)
M761 A-4713-174-A MOTOR (81) ASSY (LD/ST MOTOR)
M762 A-4713-174-A MOTOR (81) ASSY (BU U/D MOTOR)
S771 1-478-552-11 ENCODER, ROTARY (MD)
S781 1-478-551-11 ENCODER, ROTARY (ST U/D)
Ref. No. Part No. Description Remarks
VOL
