Sony HCD-D670AV - Compact Disk Deck Receiver - TC Mechanism Section 1 (TCM-220 WR2 E)

— 89 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
6-5. TC MECHANISM SECTION 1
(TCM-220WR2E)
201 X-4943-776-1 HOLDER (L) ASSY, CASSETTE
202 X-4943-775-1 HOLDER (R) ASSY, CASSETTE
203 4-959-231-11 SPRING (L), TORSION
204 4-959-232-11 SPRING (R), TORSION
205 3-354-963-01 DAMPER
* 206 3-908-611-01 FULCRUM, HOLDER
207 3-354-957-01 JOINT (LOCK LEVER)
* 208 3-354-953-01 LEVER (LOCK LEVER L)
* 209 3-354-954-01 LEVER (LOCK LEVER R)
201
207
208
205
206
205
209
207
not supplied
#1
#5
203
204
202
#5
#5
