— 9 —
2-3. CD MECHANISM DECK
2
Two screws
(BVTP 3X8)
1
Screw (BVTP 3X8)
3
Two screws
(BVTP 3X8)
4
CD mechanism deck
2-4. BU BRACKET ASSY
2
BU bracket assy
1
Yoke bracket
