Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
7373
C504 1-128-995-21 ELECT CHIP 100uF 20% 10V
C505 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C506 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C507 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C508 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C509 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C510 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C511 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN201 1-784-879-51 CONNECTOR, FFC (LIF(NON-ZIF)) 31P
CN301 1-770-425-51 CONNECTOR, FFC/FPC 16P
< IC >
IC101 6-712-082-01 IC TC94A70FG-101
IC201 6-710-808-01 IC TK63115SCL-G@GT
IC401
6-710-637-01 IC BA5826SFP-E2
IC501 6-710-840-01 IC AK5358AET-E2
IC502 6-707-870-01 IC TC74VHC157FT(EKJ)
< TRANSISTOR >
Q301 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR >
R101 1-216-813-11 METAL CHIP 220 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-295-11 SHORT CHIP 0
R105 1-216-857-11 METAL CHIP 1M 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-500-445-21 FERRITE, EMI (SMD) (2012)
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-845-11 METAL CHIP 100K 5% 1/10W
R120 1-414-444-11 FERRITE, EMI (SMD) (1608)
R121 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-853-11 METAL CHIP 470K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-857-11 METAL CHIP 1M 5% 1/10W
R135 1-216-853-11 METAL CHIP 470K 5% 1/10W
R136 1-216-837-11 METAL CHIP 22K 5% 1/10W
R139 1-216-841-11 METAL CHIP 47K 5% 1/10W
R140 1-216-864-11 SHORT CHIP 0
R142 1-216-837-11 METAL CHIP 22K 5% 1/10W
R143 1-216-841-11 METAL CHIP 47K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R151 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-857-11 METAL CHIP 1M 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-809-11 METAL CHIP 100 5% 1/10W
R160 1-216-809-11 METAL CHIP 100 5% 1/10W
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-11 SHORT CHIP 0
R202 1-216-295-11 SHORT CHIP 0
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-809-11 METAL CHIP 100 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R213 1-216-809-11 METAL CHIP 100 5% 1/10W
R214 1-216-809-11 METAL CHIP 100 5% 1/10W
R216 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R224 1-216-809-11 METAL CHIP 100 5% 1/10W
R225 1-216-845-11 METAL CHIP 100K 5% 1/10W
R226 1-216-845-11 METAL CHIP 100K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R304 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
R502 1-216-841-11 METAL CHIP 47K 5% 1/10W
R503 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R508 1-216-841-11 METAL CHIP 47K 5% 1/10W
R509 1-216-845-11 METAL CHIP 100K 5% 1/10W
R510 1-216-821-11 METAL CHIP 1K 5% 1/10W
R511 1-216-821-11 METAL CHIP 1K 5% 1/10W
R512 1-216-821-11 METAL CHIP 1K 5% 1/10W
R513 1-216-809-11 METAL CHIP 100 5% 1/10W
R514 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
CROSS FADER BOARD
******************
< JUMPER RESISTOR >
JR1300 1-216-295-11 SHORT CHIP 0
< CONNECTOR >
NO1022 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< VARIABLE RESISTOR >
RV1001 1-225-850-11 RES, VAR, SLIDE 50K (CROSS FADER)
*************************************************************
CROSS FADERBD93
