Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
74
CUE VOL BOARD
**************
< DIODE >
D1135 6-502-401-11 LED 1L434FA22E0TDT01 (A (i SELECT))
D1136 6-502-401-11 LED 1L434FA22E0TDT01 (B (i SELECT))
< JUMPER RESISTOR >
JR1170 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R1135 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1136 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1137 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1138 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1139 1-216-809-11 METAL CHIP 100 5% 1/10W
R1140 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV1135 1-227-852-11 VARIABLE RESISTOR (OTHERS) 50K (i LEVEL)
RV1136 1-227-852-11 VARIABLE RESISTOR (OTHERS) 50K
(MIC LEVEL)
< SWITCH >
S1135 1-771-410-21 SWITCH, TACTILE (i SELECT)
*************************************************************
A-1536-455-A DISPLAY BOARD, COMPLETE (US,CND,AEP,UK)
A-1538-972-A DISPLAY BOARD, COMPLETE (E3,AUS,MX,EA)
***********************
< CAPACITOR >
C1005 1-163-077-00 CERAMIC CHIP 0.1uF 50V
C1012 1-126-176-11 ELECT 220uF 20% 10V
C1016 1-126-176-11 ELECT 220uF 20% 10V
C1019 1-126-176-11 ELECT 220uF 20% 10V
C1020 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1021 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-124-257-00 ELECT 2.2uF 20% 50V
C1023 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1024 1-124-257-00 ELECT 2.2uF 20% 50V
C1025 1-126-176-11 ELECT 220uF 20% 10V
C1211 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C1212 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1213 1-126-968-11 ELECT 100uF 20% 50V
C1226 1-126-176-11 ELECT 220uF 20% 10V
C1227 1-126-176-11 ELECT 220uF 20% 10V
C1228 1-126-176-11 ELECT 220uF 20% 10V
C1229 1-126-176-11 ELECT 220uF 20% 10V
C1230 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1231 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1001 1-784-749-11 CONNECTOR, FFC 27P
* CN1012 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN1015 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< DIODE >
D1002 6-502-401-11 LED 1L434FA22E0TDT01 (PAD ΙΙ)
D1003 6-502-401-11 LED 1L434FA22E0TDT01 (PAD ΙΙ)
D1005 6-502-401-11 LED 1L434FA22E0TDT01 (PAD ΙΙ)
D1006 6-502-401-11 LED 1L434FA22E0TDT01 (PAD Ι)
D1007 6-502-401-11 LED 1L434FA22E0TDT01 (PAD Ι)
D1008 6-502-401-11 LED 1L434FA22E0TDT01 (PAD Ι)
D1009 6-502-401-11 LED 1L434FA22E0TDT01 (PAD Ι)
D1010 6-502-401-11 LED 1L434FA22E0TDT01 (PAD ΙΙ)
D1216 6-501-170-01 DIODE UDZW-TE17-6.8B
D1217 6-501-817-01 DIODE MA2J1110GLS0
D1218 6-501-817-01 DIODE MA2J1110GLS0
D1219 6-501-817-01 DIODE MA2J1110GLS0
< VACUUM FLUORESCENT DISPLAY >
FL1001 1-483-009-11 VACUUM FLUORESCENT DISPLAY
< JUMPER RESISTOR >
JR1000 1-216-296-11 SHORT CHIP 0
< CONNECTOR >
NO1021 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< TRANSISTOR >
Q1001 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1002 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1003 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1004 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1005 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1006 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1007 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1002 1-216-819-11 METAL CHIP 680 5% 1/10W
R1003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1004 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1005 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1006 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1007 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1008 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1009 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1011 1-216-817-11 METAL CHIP 470 5% 1/10W
R1012 1-216-819-11 METAL CHIP 680 5% 1/10W
R1013 1-216-817-11 METAL CHIP 470 5% 1/10W
R1014 1-216-819-11 METAL CHIP 680 5% 1/10W
R1015 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1016 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1017 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1019 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1021 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1022 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1024 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1026 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1028 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1030 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1047 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1048 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1049 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1050 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1052 1-216-296-11 SHORT CHIP 0
DISPLAYCUE VOL
Ver. 1.3
