Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
7575
R1056 1-216-809-11 METAL CHIP 100 5% 1/10W
R1057 1-216-809-11 METAL CHIP 100 5% 1/10W
R1059 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1112 1-216-864-11 SHORT CHIP 0
R1113 1-216-864-11 SHORT CHIP 0
R1114 1-216-864-11 SHORT CHIP 0
R1115 1-216-864-11 SHORT CHIP 0
R1208 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1209 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1241 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
< SWITCH >
S1002 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S1003 1-771-410-21 SWITCH, TACTILE (BEAT ON/OFF)
S1004 1-771-410-21 SWITCH, TACTILE (SURROUND)
S1005 1-771-410-21 SWITCH, TACTILE (BEAT PATTERN)
S1006 1-771-410-21 SWITCH, TACTILE (GROOVE)
S1007 1-771-410-21 SWITCH, TACTILE (OPTIONS)
S1008 1-771-410-21 SWITCH, TACTILE (ERASE)
S1009 1-771-410-21 SWITCH, TACTILE (BEAT LEVEL)
S1010 1-771-410-21 SWITCH, TACTILE (REC TO USB)
S1011 1-771-410-21 SWITCH, TACTILE (PAD Ι (BEAT BLEND))
S1012 1-771-410-21 SWITCH, TACTILE (BPM SPEED (BEAT BLEND))
S1015 1-771-410-21 SWITCH, TACTILE (PAD ΙΙ (BEAT BLEND))
S1016 1-771-410-21 SWITCH, TACTILE (BPM CONTROL
(BEAT BLEND))
*************************************************************
DLS BOARD
**********
< CAPACITOR >
C1480 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1481 1-820-048-11 CONNECTOR (LIGHTING) 5P
(D-LIGHT SYNC OUT)
< GROUND TERMINAL >
ET1480 1-537-771-21 TERMINAL BOARD, GROUND
< JACK >
J1480 1-764-767-21 JACK, PIN 2P (LINE IN 1)
< RESISTOR >
R1480 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1481 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1482 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1483 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1485 1-216-864-11 SHORT CHIP 0
*************************************************************
D-SUB BOARD
************
< CONNECTOR >
CN1490 1-821-023-11 SOCKET, D-SUB CONNECTOR 25P
(SYSTEM CONTROL)
< GROUND TERMINAL >
ET1490 1-537-771-21 TERMINAL BOARD, GROUND
*************************************************************
EJECT KEY BOARD
***************
< CONNECTOR >
CN1113 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R1160 1-216-839-11 METAL CHIP 33K 5% 1/10W
< SWITCH >
S1159 1-771-410-21 SWITCH, TACTILE (A)
*************************************************************
EQ BOARD
*********
< CONNECTOR >
* CN1017 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< RESISTOR >
R1152 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1154 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1156 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1157 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1158 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1159 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
< ROTARY ENCODER >
S1150 1-480-581-11 ENCODER, ROTARY (LOW)
S1151 1-480-581-11 ENCODER, ROTARY (MID)
S1152 1-480-581-11 ENCODER, ROTARY (HIGH)
*************************************************************
A-1536-494-A IPOD 1 BOARD, COMPLETE
**********************
< CAPACITOR >
C1551 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1553 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1554 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1555 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1556 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
C1557 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1560 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
C1561 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1550 1-820-701-11 PIN, CONNECTOR 30P (iPod 1)
< DIODE >
D1553 6-501-568-01 DIODE RB521CS-30T2R
< RESISTOR >
R1550 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1551 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1552 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1553 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1554 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R1555 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
DLSDISPLAY D-SUB EJECT KEY EQ IPOD 1
Ver. 1.4
