Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
8585
R1111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1116 1-216-819-11 METAL CHIP 680 5% 1/10W
R1117 1-216-819-11 METAL CHIP 680 5% 1/10W
R1118 1-216-819-11 METAL CHIP 680 5% 1/10W
R1119 1-216-819-11 METAL CHIP 680 5% 1/10W
R1121 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1235 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1100 1-771-410-21 SWITCH, TACTILE (L (CHANNEL A))
S1101 1-771-410-21 SWITCH, TACTILE
(MENU/RETURN (CHANNEL A))
S1102 1-771-410-21 SWITCH, TACTILE (LINE IN 1 (CHANNEL A))
S1103 1-771-410-21 SWITCH, TACTILE (iPod 1 (CHANNEL A))
S1104 1-771-410-21 SWITCH, TACTILE (l (CHANNEL A))
S1105 1-771-410-21 SWITCH, TACTILE (H S (CHANNEL A))
*************************************************************
SIDE A SEL BOARD
****************
< CONNECTOR >
* CN1101 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN1102 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< DIODE >
D1118 6-502-401-11 LED 1L434FA22E0TDT01
(ENTER (CHANNEL A))
< RESISTOR >
R1125 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1126 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1118 1-771-410-21 SWITCH, TACTILE (ENTER (CHANNEL A))
*************************************************************
SIDE B BOARD
************
< CAPACITOR >
C1220 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1222 1-126-176-11 ELECT 220uF 20% 10V
C1223 1-126-176-11 ELECT 220uF 20% 10V
< DIODE >
D1051 6-502-401-11 LED 1L434FA22E0TDT01
(H S (CHANNEL B))
D1052 6-502-401-11 LED 1L434FA22E0TDT01
(L TUNE + (CHANNEL B))
D1053 6-502-401-11 LED 1L434FA22E0TDT01
(MENU/RETURN (CHANNEL B))
D1054 6-502-401-11 LED 1L434FA22E0TDT01
(l TUNE – (CHANNEL B))
D1057 6-502-401-11 LED 1L434FA22E0TDT01 (USB)
D1058 6-502-401-11 LED 1L434FA22E0TDT01 (TUNER/BAND)
D1059 6-502-401-11 LED 1L434FA22E0TDT01
(LINE IN 2 (CHANNEL B))
D1060 6-502-401-11 LED 1L434FA22E0TDT01
(iPod 2 (CHANNEL B))
D1061 6-502-401-11 LED 1L434FA22E0TDT01 (CD)
< IC >
IC1011 6-704-046-01 IC BU2099FV
< ROTARY ENCODER >
JG1055 1-487-028-11 ENCODER, ROTARY
(MULTI JOG DIAL B)
< JUMPER RESISTOR >
JR153 1-216-864-11 SHORT CHIP 0
JR154 1-216-864-11 SHORT CHIP 0
JR155 1-216-864-11 SHORT CHIP 0
JR305 1-216-296-11 SHORT CHIP 0
JR1001 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q1055 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1137 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1053 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1054 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1055 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1060 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1061 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1062 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1063 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1064 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1065 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1066 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1067 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1068 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1070 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1076 1-216-819-11 METAL CHIP 680 5% 1/10W
R1078 1-216-819-11 METAL CHIP 680 5% 1/10W
R1080 1-216-864-11 SHORT CHIP 0
R1081 1-216-864-11 SHORT CHIP 0
R1082 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1086 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1087 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1088 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1089 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1090 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1092 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1094 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1095 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1096 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1221 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1224 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1225 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1226 1-216-819-11 METAL CHIP 680 5% 1/10W
R1227 1-216-819-11 METAL CHIP 680 5% 1/10W
< SWITCH >
S1054 1-771-410-21 SWITCH, TACTILE (
–)
S1055 1-771-410-21 SWITCH, TACTILE (iPod 2 (CHANNEL B))
S1060 1-771-410-21 SWITCH, TACTILE
(l TUNE – (CHANNEL B))
S1061 1-771-410-21 SWITCH, TACTILE
(MENU/RETURN (CHANNEL B))
S1062 1-771-410-21 SWITCH, TACTILE (CD)
SIDE A SIDE A SEL SIDE B
