Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
86
S1063 1-771-410-21 SWITCH, TACTILE (USB)
S1064 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S1065 1-771-410-21 SWITCH, TACTILE (LINE IN 2 (CHANNEL B))
S1066 1-771-410-21 SWITCH, TACTILE (
+)
S1067 1-771-410-21 SWITCH, TACTILE
(L TUNE + (CHANNEL B))
S1068 1-771-410-21 SWITCH, TACTILE (H S (CHANNEL B))
S1069 1-771-410-21 SWITCH, TACTILE (s)
*************************************************************
SIDE B SEL BOARD
****************
< CONNECTOR >
CN1008 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D1090 6-502-401-11 LED 1L434FA22E0TDT01
(ENTER (CHANNEL B))
< RESISTOR >
R1069 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1097 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1098 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1070 1-771-410-21 SWITCH, TACTILE (ENTER (CHANNEL B))
*************************************************************
USB BOARD
**********
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-124-779-00 ELECT CHIP 10uF 20% 16V
C903 1-124-779-00 ELECT CHIP 10uF 20% 16V
C904 1-124-779-00 ELECT CHIP 10uF 20% 16V
C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C908 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C909 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C910 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C912 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C913 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C914 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C915 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C916 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C917 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C918 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C919 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C920 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C921 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C922 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C930 1-165-112-11 CERAMIC CHIP 0.33uF 16V
< CONNECTOR >
CN901 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
CN903 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN907 1-784-833-51 CONNECTOR, FFC (LIF(NON-ZIF)) 21P
< DIODE >
D901 6-501-579-01 DIODE MC2837
D902 6-501-579-01 DIODE MC2837
D903 6-501-743-01 DIODE MAZ8068GMLS0
D904 6-501-743-01 DIODE MAZ8068GMLS0
< GROUND TERMINAL >
EP901 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB901 1-414-233-22 INDUCTOR, FERRITE BEAD
FB902 1-414-233-22 INDUCTOR, FERRITE BEAD
< IC >
IC901 6-808-190-01 IC TMP92CD28AFG-7AC9
IC915 6-710-887-01 IC R5523N001B-TR-F
IC921 6-704-832-01 IC IS61LV6416-10TLT
< JUMPER RESISTOR >
JR902 1-216-295-11 SHORT CHIP 0
< RESISTOR >
R901 1-216-833-11 METAL CHIP 10K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R904 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R907 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R913 1-216-845-11 METAL CHIP 100K 5% 1/10W
R915 1-216-833-11 METAL CHIP 10K 5% 1/10W
R916 1-216-864-11 SHORT CHIP 0
R917 1-216-864-11 SHORT CHIP 0
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-833-11 METAL CHIP 10K 5% 1/10W
R921 1-216-845-11 METAL CHIP 100K 5% 1/10W
R922 1-216-845-11 METAL CHIP 100K 5% 1/10W
R923 1-216-802-11 METAL CHIP 27 5% 1/10W
R924 1-216-802-11 METAL CHIP 27 5% 1/10W
R925 1-216-835-11 METAL CHIP 15K 5% 1/10W
R926 1-216-835-11 METAL CHIP 15K 5% 1/10W
R928 1-216-864-11 SHORT CHIP 0
R932 1-216-809-11 METAL CHIP 100 5% 1/10W
R933 1-216-864-11 SHORT CHIP 0
R934 1-216-833-11 METAL CHIP 10K 5% 1/10W
R937 1-216-809-11 METAL CHIP 100 5% 1/10W
R938 1-216-809-11 METAL CHIP 100 5% 1/10W
R941 1-216-845-11 METAL CHIP 100K 5% 1/10W
R942 1-216-845-11 METAL CHIP 100K 5% 1/10W
R943 1-216-845-11 METAL CHIP 100K 5% 1/10W
R944 1-216-845-11 METAL CHIP 100K 5% 1/10W
R945 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R947 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R949 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R970 1-216-809-11 METAL CHIP 100 5% 1/10W
R971 1-216-809-11 METAL CHIP 100 5% 1/10W
R972 1-216-809-11 METAL CHIP 100 5% 1/10W
R973 1-216-809-11 METAL CHIP 100 5% 1/10W
R974 1-216-809-11 METAL CHIP 100 5% 1/10W
USBSIDE B SIDE B SEL
