Sony HCD-DP700 - Components List (DSP & Front Amp); DSP Resistors and Capacitors; Front Amp Resistors; Front Amp Components

73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
R676 1-216-809-11 METAL CHIP 100 5% 1/16W
R677 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R678 1-216-833-11 METAL CHIP 10K 5% 1/16W
R679 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R680 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R681 1-216-839-11 METAL CHIP 33K 5% 1/16W
R682 1-216-809-11 METAL CHIP 100 5% 1/16W
R683 1-216-809-11 METAL CHIP 100 5% 1/16W
R684 1-216-809-11 METAL CHIP 100 5% 1/16W
R685 1-216-809-11 METAL CHIP 100 5% 1/16W
R686 1-216-809-11 METAL CHIP 100 5% 1/16W
R687 1-216-809-11 METAL CHIP 100 5% 1/16W
R688 1-216-809-11 METAL CHIP 100 5% 1/16W
R689 1-216-821-11 METAL CHIP 1K 5% 1/16W
R690 1-216-857-11 METAL CHIP 1M 5% 1/16W
R691 1-216-864-11 METAL CHIP 0 5% 1/16W
R692 1-216-809-11 METAL CHIP 100 5% 1/16W
R693 1-216-809-11 METAL CHIP 100 5% 1/16W
R694 1-216-809-11 METAL CHIP 100 5% 1/16W
R695 1-216-809-11 METAL CHIP 100 5% 1/16W
R696 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R697 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R698 1-216-852-11 METAL CHIP 390K 5% 1/16W
R699 1-216-852-11 METAL CHIP 390K 5% 1/16W
R700 1-216-833-11 METAL CHIP 10K 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R702 1-216-857-11 METAL CHIP 1M 5% 1/16W
R703 1-216-857-11 METAL CHIP 1M 5% 1/16W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R707 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-857-11 METAL CHIP 1M 5% 1/16W
R709 1-216-841-11 METAL CHIP 47K 5% 1/16W
R711 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R712 1-216-845-11 METAL CHIP 100K 5% 1/16W
R713 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R715 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R716 1-216-845-11 METAL CHIP 100K 5% 1/16W
R717 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R730 1-216-837-11 METAL CHIP 22K 5% 1/16W
R731 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R733 1-216-821-11 METAL CHIP 1K 5% 1/16W
R734 1-216-821-11 METAL CHIP 1K 5% 1/16W
R736 1-216-821-11 METAL CHIP 1K 5% 1/16W
R737 1-216-821-11 METAL CHIP 1K 5% 1/16W
R740 1-216-835-11 METAL CHIP 15K 5% 1/16W
R741 1-216-835-11 METAL CHIP 15K 5% 1/16W
R744 1-216-833-11 METAL CHIP 10K 5% 1/16W
R745 1-216-833-11 METAL CHIP 10K 5% 1/16W
R747 1-216-845-11 METAL CHIP 100K 5% 1/16W
R748 1-216-845-11 METAL CHIP 100K 5% 1/16W
R749 1-216-834-11 METAL CHIP 12K 5% 1/16W
R750 1-216-834-11 METAL CHIP 12K 5% 1/16W
R751 1-216-841-11 METAL CHIP 47K 5% 1/16W
R752 1-216-841-11 METAL CHIP 47K 5% 1/16W
R753 1-216-809-11 METAL CHIP 100 5% 1/16W
R754 1-216-809-11 METAL CHIP 100 5% 1/16W
R756 1-216-841-11 METAL CHIP 47K 5% 1/16W
R757 1-216-841-11 METAL CHIP 47K 5% 1/16W
R758 1-216-821-11 METAL CHIP 1K 5% 1/16W
R759 1-216-821-11 METAL CHIP 1K 5% 1/16W
R760 1-216-821-11 METAL CHIP 1K 5% 1/16W
R761 1-216-821-11 METAL CHIP 1K 5% 1/16W
R762 1-216-821-11 METAL CHIP 1K 5% 1/16W
R763 1-216-821-11 METAL CHIP 1K 5% 1/16W
R765 1-216-821-11 METAL CHIP 1K 5% 1/16W
R766 1-216-821-11 METAL CHIP 1K 5% 1/16W
R767 1-216-821-11 METAL CHIP 1K 5% 1/16W
R768 1-216-833-11 METAL CHIP 10K 5% 1/16W
R769 1-216-821-11 METAL CHIP 1K 5% 1/16W
R770 1-216-821-11 METAL CHIP 1K 5% 1/16W
R771 1-216-833-11 METAL CHIP 10K 5% 1/16W
R772 1-216-821-11 METAL CHIP 1K 5% 1/16W
R773 1-216-821-11 METAL CHIP 1K 5% 1/16W
R774 1-216-821-11 METAL CHIP 1K 5% 1/16W
R775 1-216-833-11 METAL CHIP 10K 5% 1/16W
R776 1-216-833-11 METAL CHIP 10K 5% 1/16W
R777 1-216-833-11 METAL CHIP 10K 5% 1/16W
R778 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MX,E51)
R779 1-216-841-11 METAL CHIP 47K 5% 1/16W
R780 1-216-841-11 METAL CHIP 47K 5% 1/16W
R781 1-216-841-11 METAL CHIP 47K 5% 1/16W
R782 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MX,E51)
R783 1-216-809-11 METAL CHIP 100 5% 1/16W
(MX,E51)
< VIBRATOR >
X601 1-579-993-21 VIBRATOR, CERAMIC (13.5MHz)
**************************************************************
A-4475-634-A FRONT AMP BOARD, COMPLETE (US)
*****************************
A-4475-675-A FRONT AMP BOARD, COMPLETE (MX,E51)
*********************************
A-4475-689-A FRONT AMP BOARD, COMPLETE (AEP)
******************************
A-4476-020-A FRONT AMP BOARD, COMPLETE (CND)
******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S (MX,E51)
< CAPACITOR >
C801 1-128-582-11 ELECT 10uF 20% 100V
(US,CND)
C801 1-126-964-11 ELECT 10uF 20% 50V
(AEP,MX,E51)
C802 1-162-292-31 CERAMIC 680PF 10% 50V
(US,CND,AEP)
C802 1-164-159-11 CERAMIC 0.1uF 50V
(MX,E51)
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-965-91 ELECT 22uF 20% 50V
(US,CND)
C804 1-126-933-11 ELECT 100uF 20% 16V
(AEP,MX,E51)
C805 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
(MX,E51)
C806 1-136-495-11 FILM 0.068uF 5% 50V
C807 1-136-495-11 FILM 0.068uF 5% 50V
DSP FRONT AMP
