Sony HCD-DP700 - Front Amp Components (Cont.); Diodes and ICs; Coils

74
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
C808 1-128-552-51 ELECT 47uF 20% 63V
(US,CND,AEP)
C808 1-128-560-11 ELECT 22uF 20% 100V
(MX,E51)
C812 1-136-165-00 FILM 0.1uF 5% 50V
(MX,E51)
C816 1-162-306-11 CERAMIC 0.01uF 30% 16V
C817 1-162-306-11 CERAMIC 0.01uF 30% 16V
(AEP)
C821 1-128-562-11 ELECT 47uF 20% 100V
C822 1-126-968-11 ELECT 100uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-382-11 ELECT 100uF 20% 10V
C833 1-126-961-11 ELECT 2.2uF 20% 50V
C834 1-104-665-11 ELECT 100uF 20% 10V
C851 1-128-582-11 ELECT 10uF 20% 100V
(US,CND)
C851 1-126-964-11 ELECT 10uF 20% 50V
(AEP,MX,E51)
C852 1-162-292-31 CERAMIC 680PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-965-91 ELECT 22uF 20% 50V
(US,CND)
C854 1-126-933-11 ELECT 100uF 20% 16V
(AEP,MX,E51)
C855 1-102-936-00 CERAMIC 3.0PF ±0.25PF 50V
(MX,E51)
C856 1-136-495-11 FILM 0.068uF 5% 50V
C857 1-136-495-11 FILM 0.068uF 5% 50V
C858 1-128-552-51 ELECT 47uF 20% 63V
(US,CND,AEP)
C858 1-128-560-11 ELECT 22uF 20% 100V
(MX,E51)
C862 1-136-165-00 FILM 0.1uF 5% 50V
(MX,E51)
C871 1-137-749-11 MYLAR 0.1uF 100V
C872 1-137-749-11 MYLAR 0.1uF 100V
C873 1-135-928-21 ELECT 2200uF 20% 63V
(US,CND,AEP)
C873 1-137-842-11 ELECT 2200uF 20% 80V
(MX,E51)
C874 1-135-928-21 ELECT 2200uF 20% 63V
(US,CND,AEP)
C874 1-137-842-11 ELECT 2200uF 20% 80V
(MX,E51)
C881 1-136-165-00 FILM 0.1uF 5% 50V
(AEP,MX,E51)
C882 1-136-165-00 FILM 0.1uF 5% 50V
(AEP,MX,E51)
C883 1-136-165-00 FILM 0.1uF 5% 50V
(AEP,MX,E51)
C884 1-136-165-00 FILM 0.1uF 5% 50V
(AEP,MX,E51)
C885 1-162-306-11 CERAMIC 0.01uF 30% 16V
(AEP,MX,E51)
C886 1-162-306-11 CERAMIC 0.01uF 30% 16V
(AEP,MX,E51)
C923 1-126-964-11 ELECT 10uF 20% 50V
C924 1-126-926-11 ELECT 1000uF 20% 10V
C925 1-126-964-11 ELECT 10uF 20% 50V
C926 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN801 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
(AEP,US,CND)
CN801 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P (MX,E51)
CN802 1-784-031-21 CONNECTOR, BOARD TO BOARD 8P
CN803 1-691-765-11 PLUG (MICRO CONNECTOR) 3P (MX,E51)
< DIODE >
D801 8-719-911-19 DIODE 1SS119-25
D802 8-719-947-65 DIODE MTZJ-T-72-16B (MX,E51)
D821 8-719-911-19 DIODE 1SS119-25
D830 8-719-911-19 DIODE 1SS119-25
D831 8-719-911-19 DIODE 1SS119-25
D851 8-719-911-19 DIODE 1SS119-25
D852 8-719-947-65 DIODE MTZJ-T-72-16B (MX,E51)
D871 8-719-510-68 DIODE D5SBA204101
D881 8-719-911-19 DIODE 1SS119-25
D891 8-719-911-19 DIODE 1SS119-25
< IC >
IC801 8-749-016-96 IC STK402-120S (US)
IC801 8-749-017-04 IC STK412-030 (MX,E51)
IC801 8-749-016-94 IC STK402-090S (AEP)
IC801 8-749-016-95 IC STK402-100S (CND)
IC922 8-759-701-59 IC NJM7809FA
IC923 8-759-088-08 IC UPC7812AHF
< COIL >
L881 1-420-872-00 COIL, AIR-CORE (AEP,MX,E51)
L882 1-420-872-00 COIL, AIR-CORE (AEP,MX,E51)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q816 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q817 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q821 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q822 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q823 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q832 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q833 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q834 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q835 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q836 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q837 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q881 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q882 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-411-11 CARBON 330 5% 1/4W
(US,CND)
R803 1-249-407-11 CARBON 150 5% 1/4W F
(MX,E51)
R803 1-249-413-11 CARBON 470 5% 1/4W F
(AEP)
FRONT AMP
