Sony HCD-DP700 - Components List (Front Amp, Head, Leaf SW); Front Amp Resistors, Relay, Thermistor; Head (A), Head (B), Leaf SW Resistors

75
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
R804 1-249-438-11 CARBON 56K 5% 1/4W
0 R805 1-220-755-11 METAL 0.22 10% 2W
0 R806 1-220-755-11 METAL 0.22 10% 2W
R807 1-249-417-11 CARBON 1K 5% 1/4W F
R808 1-249-431-11 CARBON 15K 5% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-260-076-11 CARBON 10 5% 1/2W
0 R811 1-212-881-11 FUSIBLE 100 5% 1/4W
R812 1-260-330-11 CARBON 1.5K 5% 1/2W
(MX,E51)
R816 1-249-441-11 CARBON 100K 5% 1/4W
R817 1-249-441-11 CARBON 100K 5% 1/4W
R818 1-249-441-11 CARBON 100K 5% 1/4W
(US,CND,MX,E51)
R818 1-247-881-00 CARBON 120K 5% 1/4W
(AEP)
R819 1-249-429-11 CARBON 10K 5% 1/4W
0 R820 1-202-972-61 FUSIBLE 1 5% 1/4W
R821 1-249-421-11 CARBON 2.2K 5% 1/4W F
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-429-11 CARBON 10K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W F
R825 1-249-439-11 CARBON 68K 5% 1/4W
R826 1-249-426-11 CARBON 5.6K 5% 1/4W
R827 1-249-431-11 CARBON 15K 5% 1/4W
R828 1-249-435-11 CARBON 33K 5% 1/4W
R830 1-249-425-11 CARBON 4.7K 5% 1/4W F
R831 1-249-425-11 CARBON 4.7K 5% 1/4W F
R833 1-249-425-11 CARBON 4.7K 5% 1/4W F
R834 1-249-433-11 CARBON 22K 5% 1/4W
R835 1-249-435-11 CARBON 33K 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R839 1-249-437-11 CARBON 47K 5% 1/4W
R840 1-249-438-11 CARBON 56K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-411-11 CARBON 330 5% 1/4W
(US,CND)
R853 1-249-407-11 CARBON 150 5% 1/4W F
(MX,E51)
R853 1-249-413-11 CARBON 470 5% 1/4W F
(AEP)
R854 1-249-438-11 CARBON 56K 5% 1/4W
0 R855 1-220-755-11 METAL 0.22 10% 2W
0 R856 1-220-755-11 METAL 0.22 10% 2W
R857 1-249-417-11 CARBON 1K 5% 1/4W F
R858 1-249-431-11 CARBON 15K 5% 1/4W
R859 1-249-441-11 CARBON 100K 5% 1/4W
R860 1-260-076-11 CARBON 10 5% 1/2W
0 R861 1-212-881-11 FUSIBLE 100 5% 1/4W
R862 1-260-330-11 CARBON 1.5K 5% 1/2W
(MX,E51)
R871 1-249-441-11 CARBON 100K 5% 1/4W
R872 1-249-441-11 CARBON 100K 5% 1/4W
R880 1-216-457-00 METAL OXIDE 1.2K 5% 2W
(US,CND,AEP)
0 R880 1-215-890-11 METAL OXIDE 470 5% 2W
(MX,E51)
R881 1-260-076-11 CARBON 10 5% 1/2W
(AEP,MX,E51)
R882 1-260-076-11 CARBON 10 5% 1/2W
(AEP,MX,E51)
R883 1-260-076-11 CARBON 10 5% 1/2W
(AEP,MX,E51)
R884 1-260-076-11 CARBON 10 5% 1/2W
(AEP,MX,E51)
R885 1-249-437-11 CARBON 47K 5% 1/4W
R886 1-249-437-11 CARBON 47K 5% 1/4W
R887 1-249-429-11 CARBON 10K 5% 1/4W
R888 1-249-437-11 CARBON 47K 5% 1/4W
R889 1-249-429-11 CARBON 10K 5% 1/4W
R890 1-249-441-11 CARBON 100K 5% 1/4W
< RELAY >
RY881 1-515-920-11 RELAY
< THERMISTOR >
TH801 1-807-796-11 THERMISTOR
< TERMINAL >
TM801 1-694-677-12 TERMINAL BOARD (4P)
**************************************************************
1-676-220-11 HEAD (A) BOARD
**************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD (B) BOARD
**************
< CONNECTOR >
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119-25
D1002 8-719-911-19 DIODE 1SS119-25
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
FRONT AMP HEAD (A) HEAD (B) LEAF SW
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
