Sony HCD-DP700 - Leaf SW Components; Transistors and Resistors; Variable Resistors and Switches

76
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K (HIGH, SPEED)
RV1002 1-241-785-11 RES, ADJ, CARBON 10K (NORM, SPEED)
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-536-12 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-536-12 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1008 1-771-536-12 SWITCH, LEAF (DECK B 120/70)
S1009 1-771-536-12 SWITCH, LEAF (DECK B REC)
**************************************************************
A-4475-627-A MAIN BOARD, COMPLETE (US,CND)
*****************************
A-4475-671-A MAIN BOARD, COMPLETE (E51)
**************************
A-4475-685-A MAIN BOARD, COMPLETE (AEP)
**************************
A-4476-032-A MAIN BOARD, COMPLETE (MX)
*************************
< CAPACITOR >
C1 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(AEP,MX,E51)
C3 1-104-660-91 ELECT 47uF 20% 16V
C4 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(US,CND)
C7 1-216-864-11 METAL CHIP 0 5% 1/16W
(MX,E51)
C11 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C12 1-104-660-91 ELECT 47uF 20% 16V
C13 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C14 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C15 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C16 1-104-660-91 ELECT 47uF 20% 16V
C17 1-126-959-11 ELECT 0.47uF 20% 50V
C18 1-126-960-11 ELECT 1uF 20% 50V
C19 1-126-960-11 ELECT 1uF 20% 50V
C20 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,AEP)
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(MX,E51)
C21 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,AEP)
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(MX,E51)
C22 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C23 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-126-964-11 ELECT 10uF 20% 50V
C26 1-164-471-11 CERAMIC CHIP 680PF 5% 50V
(US,CND,MX,E51)
C26 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP)
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-126-963-11 ELECT 4.7uF 20% 50V
C29 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C30 1-126-962-11 ELECT 3.3uF 20% 50V
C31 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C32 1-126-963-11 ELECT 4.7uF 20% 50V
C34 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C35 1-104-660-91 ELECT 47uF 20% 16V
C36 1-126-963-11 ELECT 4.7uF 20% 50V
C38 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C39 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C40 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C41 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C42 1-162-940-11 CERAMIC CHIP 9PF 0.5PF 50V
C43 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C46 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C48 1-162-947-11 CERAMIC CHIP 33PF 5% 50V
(AEP)
C49 1-162-947-11 CERAMIC CHIP 33PF 5% 50V
(AEP)
C51 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C52 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C56 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C57 1-104-660-91 ELECT 47uF 20% 16V
C58 1-126-961-11 ELECT 2.2uF 20% 50V
C59 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C60 1-104-660-91 ELECT 47uF 20% 16V
C61 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C62 1-126-959-11 ELECT 0.47uF 20% 50V
C63 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C69 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C81 1-164-363-11 CERAMIC CHIP 560PF 5% 50V
(AEP)
C82 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP)
C83 1-126-964-11 ELECT 10uF 20% 50V
(AEP)
C84 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(AEP)
C85 1-126-961-11 ELECT 2.2uF 20% 50V
(AEP)
C86 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(AEP)
C87 1-164-363-11 CERAMIC CHIP 560PF 5% 50V
(AEP)
C88 1-126-961-11 ELECT 2.2uF 20% 50V
(AEP)
MAINLEAF SW
