78
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
MAIN
C499 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-136-165-00 FILM 0.1uF 5% 50V
C503 1-136-165-00 FILM 0.1uF 5% 50V
C504 1-109-953-11 ELECT 2.2uF 20% 50V
C505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C506 1-107-717-11 ELECT 47uF 20% 50V
C511 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C512 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C551 1-104-665-11 ELECT 100uF 20% 10V
C552 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C951 1-126-943-11 ELECT 2200uF 20% 25V
(US,CND,AEP)
C951 1-126-953-11 ELECT 2200uF 20% 35V
(MX,E51)
C952 1-130-483-00 MYLAR 0.01uF 5% 50V
C953 1-130-483-00 MYLAR 0.01uF 5% 50V
C954 1-126-944-11 ELECT 3300uF 20% 25V
C955 1-130-483-00 MYLAR 0.01uF 5% 50V
C956 1-130-483-00 MYLAR 0.01uF 5% 50V
C961 1-126-961-11 ELECT 2.2uF 20% 50V
C971 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C972 1-126-935-11 ELECT 470uF 20% 16V
C973 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C974 1-126-916-11 ELECT 1000uF 20% 6.3V
C975 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C976 1-126-916-11 ELECT 1000uF 20% 6.3V
C977 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< FILTER >
CF1 1-760-023-11 FILTER, CERAMIC (US,CND,MX,E51)
CF1 1-579-185-21 FILTER, CERAMIC (AEP)
CF2 1-760-023-11 FILTER, CERAMIC (US,CND,MX,E51)
CF2 1-579-185-21 FILTER, CERAMIC (AEP)
< CONNECTOR >
* CN101 1-774-876-21 CONNECTOR, BOARD TO BOARD 8P
CN102 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN103 1-784-038-21 CONNECTOR, BOARD TO BOARD 9P
* CN104 1-564-518-11 PLUG, CONNECTOR 3P
CN201 1-568-864-11 CONNECTOR, FFC 21P
CN304 1-784-778-11 CONNECTOR, FFC 17P
CN401 1-793-766-11 CONNECTOR, BOARD TO BOARD 30P
CN402 1-506-469-11 PIN, CONNECTOR 4P
CN501 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN502 1-779-291-11 CONNECTOR,FFC(LIF(NON-ZIF))23P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D81 8-719-988-61 DIODE 1SS355TE-17 (AEP)
D111 8-719-988-61 DIODE 1SS355TE-17
D112 8-719-056-82 DIODE UDZ-TE-17-6.2B
D113 8-719-056-83 DIODE UDZ-TE-17-6.8B
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D950 8-719-028-23 DIODE D3SBA20-4101
D951 8-719-028-23 DIODE D3SBA20-4101
D961 8-719-988-61 DIODE 1SS355TE-17
D962 8-719-988-61 DIODE 1SS355TE-17
D971 8-719-200-82 DIODE 11ES2-TB5
D972 8-719-200-82 DIODE 11ES2-TB5
D973 8-719-200-82 DIODE 11ES2-TB5
D974 8-719-200-82 DIODE 11ES2-TB5
D975 8-719-200-82 DIODE 11ES2-TB5
D981 8-719-200-82 DIODE 11ES2-TB5
D982 8-719-200-82 DIODE 11ES2-TB5
D983 8-719-200-82 DIODE 11ES2-TB5
D984 8-719-200-82 DIODE 11ES2-TB5
< FRONT END >
FE1 1-693-477-12 FRONT END (3 GANGS) (MX,E51)
FE2 1-693-478-11 FRONT END (FM3 GANGS) (US,CND)
FE3 1-693-496-11 FRONT END (4 GANG) (AEP)
< IC >
IC11 8-759-828-33 IC LA1845
IC51 8-759-584-70 IC LC72131
IC81 8-759-541-48 IC BU1924 (AEP)
IC301 8-759-652-02 IC HA12226F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC401 8-759-712-89 IC M30622MGA-A36FP
IC501 8-759-635-63 IC M51943BSL-TP
IC551 8-759-491-46 IC TC74VHCT04AFT(EL)
< IFT >
IFT11 1-435-848-11 TRANSFORMER,IF(CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
JR3 1-216-864-11 METAL CHIP 0 5% 1/16W
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
JR6 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND)
JR7 1-216-864-11 METAL CHIP 0 5% 1/16W
JR8 1-216-864-11 METAL CHIP 0 5% 1/16W
JR9 1-216-864-11 METAL CHIP 0 5% 1/16W
(MX,E51)
JR10 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND)
JR11 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,MX,E51)
JR12 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND)
JR13 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,MX,E51)
JR14 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP)
JR15 1-216-864-11 METAL CHIP 0 5% 1/16W
To Next Page
