Sony HCD-DP700 - Main Board Components (Cont.); Transistors; Resistors; Coils and Ferrite Beads

79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
MAIN
JR19 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND,MX,E51)
JR21 1-216-864-11 METAL CHIP 0 5% 1/16W
JR22 1-216-864-11 METAL CHIP 0 5% 1/16W
JR23 1-216-864-11 METAL CHIP 0 5% 1/16W
JR24 1-216-864-11 METAL CHIP 0 5% 1/16W
JR25 1-216-864-11 METAL CHIP 0 5% 1/16W
JR26 1-216-864-11 METAL CHIP 0 5% 1/16W
JR27 1-216-864-11 METAL CHIP 0 5% 1/16W
JR29 1-216-864-11 METAL CHIP 0 5% 1/16W
JR30 1-216-864-11 METAL CHIP 0 5% 1/16W
JR31 1-216-864-11 METAL CHIP 0 5% 1/16W
JR32 1-216-864-11 METAL CHIP 0 5% 1/16W
JR33 1-216-864-11 METAL CHIP 0 5% 1/16W
JR34 1-216-864-11 METAL CHIP 0 5% 1/16W
JR201 1-216-864-11 METAL CHIP 0 5% 1/16W
JR203 1-216-864-11 METAL CHIP 0 5% 1/16W
JR400 1-216-864-11 METAL CHIP 0 5% 1/16W
JR416 1-216-864-11 METAL CHIP 0 5% 1/16W
JR418 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND,MX,E51)
JR420 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND,MX,E51)
JR462 1-216-864-11 METAL CHIP 0 5% 1/16W
JR493 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP)
JR498 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L41 1-412-957-11 INDUCTOR 33uH (AEP)
L81 1-412-963-11 INDUCTOR 100uH (AEP)
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
< FERRITE BEAD >
FB207 1-412-473-51 INDUCTOR (SMALL TYPE) 0uH
< FILTER >
LPF11 1-234-612-11 FILTER, LOW PASS
LPF12 1-234-612-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-055-80 TRANSISTOR 2SC1674LK-TP
Q2 8-729-422-57 TRANSISTOR BN1A4M-TP
Q11 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q12 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q81 8-729-620-05 TRANSISTOR 2SC2603TP-EF (AEP)
Q111 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q112 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q113 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q114 8-729-900-36 TRANSISTOR BA1F4M-TP
Q121 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q141 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q171 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q301 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q302 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q304 8-729-900-63 TRANSISTOR BN1F4M-TP
Q305 8-729-900-80 TRANSISTOR BA1A4M-TP
Q391 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q392 8-729-900-80 TRANSISTOR BA1A4M-TP
Q393 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q394 8-729-900-80 TRANSISTOR BA1A4M-TP
Q395 8-729-900-80 TRANSISTOR BA1A4M-TP
Q396 8-729-116-57 TRANSISTOR 2SB1068TP-K
Q397 8-729-900-80 TRANSISTOR BA1A4M-TP
Q501 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q502 8-729-900-63 TRANSISTOR BN1F4M-TP
Q503 8-729-900-63 TRANSISTOR BN1F4M-TP
Q504 8-729-900-63 TRANSISTOR BN1F4M-TP
Q505 8-729-900-36 TRANSISTOR BA1F4M-TP
Q506 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q507 8-729-422-57 TRANSISTOR BN1A4M-TP
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R3 1-216-805-11 METAL CHIP 47 5% 1/16W
R4 1-216-805-11 METAL CHIP 47 5% 1/16W
R5 1-216-819-11 METAL CHIP 680 5% 1/16W
R6 1-216-815-11 METAL CHIP 330 5% 1/16W
R7 1-216-819-11 METAL CHIP 680 5% 1/16W
R8 1-216-821-11 METAL CHIP 1K 5% 1/16W
R10 1-216-814-11 METAL CHIP 270 5% 1/16W
R12 1-216-833-11 METAL CHIP 10K 5% 1/16W
R13 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R14 1-216-814-11 METAL CHIP 270 5% 1/16W
R15 1-216-843-11 METAL CHIP 68K 5% 1/16W
R16 1-216-837-11 METAL CHIP 22K 5% 1/16W
R17 1-216-839-11 METAL CHIP 33K 5% 1/16W
R18 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R19 1-216-833-11 METAL CHIP 10K 5% 1/16W
R20 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US,CND,MX,E51)
R21 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP)
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R23 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R24 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US,CND,MX,E51)
R24 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP)
R25 1-216-809-11 METAL CHIP 100 5% 1/16W
R26 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R27 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R28 1-216-849-11 METAL CHIP 220K 5% 1/16W
R29 1-216-849-11 METAL CHIP 220K 5% 1/16W
R30 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R31 1-216-864-11 METAL CHIP 0 5% 1/16W
R41 1-216-833-11 METAL CHIP 10K 5% 1/16W
R42 1-216-845-11 METAL CHIP 100K 5% 1/16W
R43 1-216-839-11 METAL CHIP 33K 5% 1/16W
R55 1-216-833-11 METAL CHIP 10K 5% 1/16W
R56 1-216-833-11 METAL CHIP 10K 5% 1/16W
R58 1-216-809-11 METAL CHIP 100 5% 1/16W
R59 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R60 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
