Sony HCD-DP900D - Page 55

55
HCD-DP900D
DescriptionPin NamePin No. I/O
101 VSS — Ground
102 HA0 O Address bus to SRAM
103 HA1 O Address bus to SRAM
104 HA2 O Address bus to SRAM
105 HA3 O Address bus to SRAM
106 HA4 O Address bus to SRAM
107 HA5 O Address bus to SRAM
108 HA6 O Address bus to SRAM
109 HA7 O Address bus to SRAM
110 VCC I Power supply +3.3V
111 HA8 O Address bus to SRAM
112 HA9 O Address bus to SRAM
113 HA10 O Address bus to SRAM
114 HA11 O Address bus to SRAM
115 HA12 O Address bus to SRAM
116 HA13 O Address bus to SRAM
117 HA14 O Address bus to SRAM
118 HA15 O Address bus to SRAM
119 VSS — Ground
120 HA16 O Address bus to SRAM
