HCD-DP900D
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
MY : Malaysia model
SP : Singapore model
TH : Thai model
MX : Mexican model
EA : Saudi Arabia
• Refer to servicing notes (page 4) for discrimination
of TYPE A/B.
When indicating parts by reference
number, please include the board
name.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
CD PANEL BOARD (included in PANEL BOARD)
*************
< DIODE >
D1114 8-719-057-97 DIODE SEL5923A-TP15 (DISC 1)
D1115 8-719-057-97 DIODE SEL5923A-TP15 (DISC 2)
D1116 8-719-057-97 DIODE SEL5923A-TP15 (DISC 3)
D1117 8-719-071-44 DIODE SELS5223C-TP15 (`/1)
< TRANSISTOR >
Q1114 8-729-900-80 TRANSISTOR DTC114ES
Q1115 8-729-900-80 TRANSISTOR DTC114ES
Q1116 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R1138 1-249-407-11 CARBON 150 5% 1/4W F
R1139 1-249-407-11 CARBON 150 5% 1/4W F
R1140 1-249-407-11 CARBON 150 5% 1/4W F
R1141 1-249-417-11 CARBON 1K 5% 1/4W F
R1150 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1151 1-249-422-11 CARBON 2.7K 5% 1/4W F
R1152 1-249-424-11 CARBON 3.9K 5% 1/4W F
R1153 1-249-426-11 CARBON 5.6K 5% 1/4W
R1154 1-249-428-11 CARBON 8.2K 5% 1/4W F
< SWITCH >
S1110 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE )
S1111 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP EX-CHANGE)
S1112 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1113 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1114 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S1115 1-762-875-21 SWITCH, KEYBOARD (`/1)
******************************************************
1-682-793-11 DIODE BOARD
**********
< DIODE >
D731 8-719-082-30 DIODE SIR-34ST3FK
******************************************************
1-682-790-11 DRIVER BOARD
***********
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-68 DIODE MTZJ-T-72-3.9A
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
******************************************************
A-4475-667-A DSP BOARD, COMPLETE (E,MX,SP,MY,EA)
A-4475-988-A DSP BOARD, COMPLETE (TH)
*****************************
< CAPACITOR >
C601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C611 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C613 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C614 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C615 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C616 1-126-934-11 ELECT 220uF 20% 10V
C617 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C618 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C619 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-126-934-11 ELECT 220uF 20% 10V
C624 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C625 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
CD PANEL
DIODE
DRIVER
DSP
Ver 1.3 2003.01
