HCD-DP900D
5454
6-33. IC PIN FUNCTIONS DESCRIPTION
DescriptionPin NamePin No. I/O
• IC103 MB91307APFV-G-BND-E1 DVD SYSTEM CONTROL (MB BOARD (4/5))
DescriptionPin Name
Pin No.
I/O
1 HA17 O Address bus to SRAM
2 HA18 O Address bus to SRAM
3 HA19 O Address bus to SRAM
4 HA20 O Address bus to SRAM
5 HA21 O Address bus to SRAM
6 HA22 O Address bus to SRAM (Not used)
7 WP O Chip select signal output to EEPROM
8 TRM/XKRCS O Not used (open)
9 AVCC I Power supply +3.3V
10 AVRH I A/D reference voltage input (Connected to AVCC)
11 AVSS — Ground
12 AN0 I A/D input pin (mode set)
13 AN1 I A/D input pin (mode set)
14 AN2 I A/D input pin (mode set)
15 AN3 I A/D input pin (mode set)
16 INT0 I HIREQO signal input from CXD1933Q
17 INT1 I XINT signal input from CXD9635R
18 INT2 I HINT signal input from CXD9635R
19 INT3 I FGAINT signal input from LC22004A
20 INT4 I XIFINT signal input from M30622MGA
21 INT5 I Not used (open)
22 INT6 I Not used (open)
23 INT7 I Not used (open)
24 VCC I Power supply +3.3V
25 SI0 I Serial data input from M30622MGA
26 SO0 O Serial data output to M30622MGA
27 SC0 O Clock output to M30622MGA
28 SI1 I Not used (open)
29 SO1 O Not used (open)
30 SC1 O Not used (open)
31 SI2 I Test serial data input
32 SO2 O Test serial data output
33 DSENS O Not used (open)
34 VSS — Ground
35 XRST O Reset signal output
36 XARPRST O XARP reset signal output to CXD9635R
37 RGBSEL/MICMUTE O Not used (open)
38 SDA I/O Serial data input/output to EEPROM
39 SCL O Serial clock output to EEPROM
40 TRM+XKRRST O Not used (open)
41 EUROV/V/CLAPSW1 O Not used (open)
42 DISCEXT/CLPSW0 O Not used (open)
43 MD0 I Mode signal input (connected to VCC)
44 MD1 I Mode signal input (connected to VSS)
45 MD2 I Mode signal input (connected to VSS)
46 DREQ0 I DMA external transfer request input
47 DACK0 O DMA external transfer request acknowledge output
48 XDRVMUTE O Mute signal output to FAN8034
49 DREQ1 I DMA external transfer request input
50 DACK1 O DMA external transfer request acknowledge output
51 XIFCS O XIFCS signal output to M30622MGA
52 VSS — Ground
53 X1 I External crystal terminal (16.5MHz)
54 X0 O External crystal terminal (16.5MHz)
55 VCC I Power supply +3.3V
56 CKSW1 I Not used (connected toVCC)
57 OCSW1 I Not used (connected toVCC)
58 CS0X O Chip select signal output to FLASH RAM
59 CS1X O Not used (open)
60 CS2X O AVDCS2 signal output to CXD1933Q
61 CS3X O AVDCS3 signal output to CXD1933Q
62 CS4X O XARPCS signal output to CXD1933Q
63 CS5X O XSPDCS signal output to CXD1933Q
64 C — External capacitor terminal
65 CS6X O XFAGCS signal output to CXD1933Q
66 CS7X O Not used (open)
67 XWAIT I XWAIT signal input from CXD1933Q
68 BGRNTX I Not used (connected toVCC)
69 BGR O Not used (open)
70 XRD O Out enable signal output to FLASH RAM
71 XWRH O Write signal output to FLASH RAM
72 XWRL O Not used (open)
73 XMIX I Not used (connected toVCC)
74 HSTX I Not used (connected toVCC)
75 VSS — Ground
76 XFRRST I System reset input from M30622MGA
77 CPUCK O Clock signal output to LC22004A
78 OCSW2 I Not used (connected toVCC)
79 XBACK I Not used (connected toVCC)
80 VESCS/X39CS I Not used (connected toVCC)
81 48/44.1K O Audio clock control signal output
82 WIDE O WIDE control signal output
83 MAMUTE I System OK signal input to M30622MGA
84 XLDON O Laser diode ON signal output
85 HD0 I/O Data input/output to SRAM
86 HD1 I/O Data input/output to SRAM
87 HD2 I/O Data input/output to SRAM
88 HD3 I/O Data input/output to SRAM
89 HD4 I/O Data input/output to SRAM
90 HD5 I/O Data iniput/output to SRAM
91 HD6 I/O Data input/output to SRAM
92 HD7 I/O Data input/output to SRAM
93 HD8 I/O Data input/output to SRAM
94 HD9 I/O Data input/output to SRAM
95 HD10 I/O Data input/output to SRAM
96 HD11 I/O Data input/output to SRAM
97 HD12 I/O Data input/output to SRAM
98 HD13 I/O Data input/output to SRAM
99 HD14 I/O Data input/output to SRAM
100 HD15 I/O Data input/output to SRAM
To Next Page
