Sony HCD-DP900D - Electrical Parts List - MB and Related Boards; MB Board Capacitors List; MB Board Connectors List; MB Board Ferrite Beads List

82
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
C501 1-126-193-11 ELECT 1uF 20% 50V
C502 1-117-370-11 CERAMIC CHIP 10uF 10V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-117-370-11 CERAMIC CHIP 10uF 10V
C506 1-117-370-11 CERAMIC CHIP 10uF 10V
C508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C511 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C512 1-126-246-11 ELECT CHIP 220uF 20% 4V
C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C514 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C519 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C520 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C522 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C523 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C524 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C525 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C526 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C529 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C530 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C532 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C533 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C534 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C535 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C536 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C537 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C538 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C539 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C540 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C541 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C542 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C545 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C546 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C547 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C712 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C716 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C717 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C721 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C722 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C741 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C742 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C743 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C744 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C745 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C764 1-126-193-11 ELECT 1uF 20% 50V
C765 1-126-193-11 ELECT 1uF 20% 50V
C766 1-126-193-11 ELECT 1uF 20% 50V
< CONNECTOR >
CN008 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN009 1-784-135-11 CONNECTOR (FFC) 9P
CN010 1-784-146-11 CONNECTOR (FFC) 25P
* CN011 1-778-867-11 CONNECTOR, FFC/FPC 6P
CN101 1-784-371-21 CONNECTOR, FFC/FPC 12P
CN103 1-793-687-11 PIN, CONNECTOR (1.5MM) (SMD)5P
CN202 1-766-382-21 PIN, CONNECTOR (1.5MM)(SMD)10P
CN404 1-793-687-11 PIN, CONNECTOR (1.5MM) (SMD)5P
< FERRITE BEAD >
FB007 1-469-324-21 FERRITE 0UH
FB008 1-469-324-21 FERRITE 0UH
FB009 1-469-324-21 FERRITE 0UH
FB010 1-469-324-21 FERRITE 0UH
FB011 1-469-324-21 FERRITE 0UH
FB012 1-469-324-21 FERRITE 0UH
FB112 1-216-864-11 METAL CHIP 0 5% 1/16W
FB711 1-216-864-11 METAL CHIP 0 5% 1/16W
FB712 1-216-864-11 METAL CHIP 0 5% 1/16W
FB714 1-216-864-11 METAL CHIP 0 5% 1/16W
< FILTER >
FL003 1-234-177-21 FILTER, CHIP EMI
FL004 1-234-177-21 FILTER, CHIP EMI
FL005 1-233-893-21 FILTER, CHIP EMI
FL101 1-233-893-21 FILTER, CHIP EMI
FL102 1-233-893-21 FILTER, CHIP EMI
FL103 1-233-893-21 FILTER, CHIP EMI
FL202 1-233-893-21 FILTER, CHIP EMI
FL203 1-233-893-21 FILTER, CHIP EMI
FL204 1-234-177-21 FILTER, CHIP EMI
FL501 1-233-893-21 FILTER, CHIP EMI
FL502 1-233-893-21 FILTER, CHIP EMI
FL505 1-234-177-21 FILTER, CHIP EMI
< IC >
IC006 6-700-398-01 IC uPC2918T-E1
IC101 8-759-640-41 IC BR24C08F-E2
IC102 8-759-831-81 IC IMIC6001BTD
IC103 8-759-829-75 IC MB91307APFV-G-BND-E1
IC106 8-759-645-76 IC TC74VHCT32AFT
IC107 8-759-826-41 IC MBM29DL324BE-90PFTN
IC202 6-700-740-01 IC LC22004A-RJ6-TBM-E
IC301 8-759-599-45 IC MM1385ENLE
IC302 8-759-828-01 IC CXD9635R
IC303 8-759-683-75 IC MSM51V8160F-60TSKR1
IC401 8-759-826-42 IC FAN8034
IC501 8-759-832-30 IC TK71518ASCL
IC502 8-759-599-45 IC MM1385ENLE
IC503 8-752-399-55 IC CXD1932Q
IC504 8-759-663-74 IC HY57V161610DTC-7TR
IC505 8-759-663-74 IC HY57V161610DTC-7TR
IC701 8-759-680-28 IC BA7666FS-E2
< COIL >
L701 1-412-788-41 INDUCTOR 10uH
L711 1-412-790-31 INDUCTOR 15uH
L713 1-412-790-31 INDUCTOR 15uH
L715 1-412-790-31 INDUCTOR 15uH
< TRANSISTOR >
Q711 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q712 1-801-806-11 TRANSISTOR DTC144EKA
MB
