Sony HCD-DP900D - Electrical Parts List - MB Board (Cont.); MB Board Resistors List (Cont.)

84
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP900D
R337 1-216-809-11 METAL CHIP 100 5% 1/16W
R338 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R341 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R342 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R343 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R344 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R345 1-216-833-11 METAL CHIP 10K 5% 1/16W
R349 1-216-838-11 METAL CHIP 27K 5% 1/16W
R350 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R351 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R352 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R356 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R368 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R384 1-216-797-11 METAL CHIP 10 5% 1/16W
R385 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R406 1-216-846-11 METAL CHIP 120K 5% 1/16W
R407 1-216-846-11 METAL CHIP 120K 5% 1/16W
R408 1-216-847-11 METAL CHIP 150K 5% 1/16W
R409 1-216-847-11 METAL CHIP 150K 5% 1/16W
R410 1-216-842-11 METAL CHIP 56K 5% 1/16W
R411 1-216-842-11 METAL CHIP 56K 5% 1/16W
R412 1-216-850-11 METAL CHIP 270K 5% 1/16W
R413 1-216-833-11 METAL CHIP 10K 5% 1/16W
R414 1-216-853-11 METAL CHIP 470K 5% 1/16W
R415 1-216-846-11 METAL CHIP 120K 5% 1/16W
R416 1-216-855-11 METAL CHIP 680K 5% 1/16W
R417 1-216-833-11 METAL CHIP 10K 5% 1/16W
R418 1-216-839-11 METAL CHIP 33K 5% 1/16W
R419 1-216-839-11 METAL CHIP 33K 5% 1/16W
R420 1-216-853-11 METAL CHIP 470K 5% 1/16W
R421 1-216-839-11 METAL CHIP 33K 5% 1/16W
R422 1-216-839-11 METAL CHIP 33K 5% 1/16W
R423 1-216-839-11 METAL CHIP 33K 5% 1/16W
R424 1-216-839-11 METAL CHIP 33K 5% 1/16W
R425 1-216-849-11 METAL CHIP 220K 5% 1/16W
R426 1-216-853-11 METAL CHIP 470K 5% 1/16W
R427 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R428 1-216-839-11 METAL CHIP 33K 5% 1/16W
R429 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R430 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R431 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R432 1-216-833-11 METAL CHIP 10K 5% 1/16W
R433 1-216-833-11 METAL CHIP 10K 5% 1/16W
R434 1-216-815-11 METAL CHIP 330 5% 1/16W
R435 1-216-833-11 METAL CHIP 10K 5% 1/16W
R439 1-216-864-11 METAL CHIP 0 5% 1/16W
R507 1-216-809-11 METAL CHIP 100 5% 1/16W
R508 1-216-864-11 METAL CHIP 0 5% 1/16W
R509 1-216-864-11 METAL CHIP 0 5% 1/16W
R510 1-216-833-11 METAL CHIP 10K 5% 1/16W
R511 1-216-813-11 METAL CHIP 220 5% 1/16W
R512 1-216-813-11 METAL CHIP 220 5% 1/16W
R513 1-216-813-11 METAL CHIP 220 5% 1/16W
R514 1-216-813-11 METAL CHIP 220 5% 1/16W
R515 1-216-813-11 METAL CHIP 220 5% 1/16W
R516 1-216-813-11 METAL CHIP 220 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R521 1-216-864-11 METAL CHIP 0 5% 1/16W
R522 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R524 1-216-833-11 METAL CHIP 10K 5% 1/16W
R525 1-216-833-11 METAL CHIP 10K 5% 1/16W
R532 1-216-833-11 METAL CHIP 10K 5% 1/16W
R533 1-216-797-11 METAL CHIP 10 5% 1/16W
R554 1-216-797-11 METAL CHIP 10 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R711 1-218-289-11 RES-CHIP 510 5% 1/16W
R712 1-218-289-11 RES-CHIP 510 5% 1/16W
R713 1-218-289-11 RES-CHIP 510 5% 1/16W
R717 1-218-285-11 RES-CHIP 75 5% 1/16W
R718 1-218-285-11 RES-CHIP 75 5% 1/16W
R719 1-218-285-11 RES-CHIP 75 5% 1/16W
R724 1-216-833-11 METAL CHIP 10K 5% 1/16W
R725 1-216-833-11 METAL CHIP 10K 5% 1/16W
R737 1-216-864-11 METAL CHIP 0 5% 1/16W
R738 1-216-864-11 METAL CHIP 0 5% 1/16W
< VARIABLE RESISTOR >
RV501 1-223-583-11 RES, ADJ, CARBON 1K
< VIBRATOR >
X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz)
X102 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
******************************************************
1-682-791-11 MOTOR BOARD
***********
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
CN723 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
< RESISTOR >
R721 1-249-415-11 CARBON 680 5% 1/4W F
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
******************************************************
1-680-279-11 OPT IN BOARD
***********
< CAPACITOR >
C1195 1-126-791-11 ELECT 10uF 20% 16V
C1196 1-164-159-11 CERAMIC 0.1uF 50V
< FERRITE BEAD >
FB1195 1-412-473-21 INDUCTOR 0UH
< IC >
IC1195 8-749-018-63 IC GP1FA501RZ
******************************************************
A-4727-155-A PANEL BOARD, COMPLETE (including CD
PANEL BOARD) (E,MX,SP,MY,EA)
A-4727-219-A PANEL BOARD, COMPLETE (Iincluding CD
PANEL BOARD) (TH)
******************************
MB
MOTOR OPT IN PANEL
Ver 1.1 2002.03
