– 117 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-672-195-11 LED (PANEL) BOARD
*****************
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D672 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D673 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D674 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D675 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
< RESISTOR >
R600 1-249-410-11 CARBON 270 5% 1/4W F
**************************************************************
* A-4417-496-A MAIN BOARD, COMPLETE (W300/W5000)
********************
* A-4417-507-A MAIN BOARD, COMPLETE (XB500)
********************
* A-4417-516-A MAIN BOARD, COMPLETE
********************
(DR4:E,TH,AR,MX/DR440)
* A-4417-562-A MAIN BOARD, COMPLETE (DR6:E,AR,MX)
********************
* A-4417-567-A MAIN BOARD, COMPLETE (DR5:E,AR,MX)
********************
* A-4417-970-A MAIN BOARD, COMPLETE (DR6:SP,MY)
********************
* A-4417-974-A MAIN BOARD, COMPLETE (DR5:SP)
********************
* A-4417-982-A MAIN BOARD, COMPLETE (DR4:EA)
********************
* A-4417-988-A MAIN BOARD, COMPLETE (DR4:SP,AUS)
********************
4-875-327-31 HEAT SINK
4-951-620-01 SCREW (2.6X8), +BVTP
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-136-158-00 FILM 0.027uF 5% 50V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-130-480-00 MYLAR 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-130-473-00 MYLAR 0.0015uF 5% 50V
C117 1-136-153-00 FILM 0.01uF 5% 50V
C118 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C119 1-130-479-00 MYLAR 0.0047uF 5% 50V
C120 1-130-477-00 MYLAR 0.0033uF 5% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C123 1-136-169-00 FILM 0.22uF 5% 50V
C124 1-136-169-00 FILM 0.22uF 5% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
C131 1-104-664-11 ELECT 47uF 20% 16V
C132 1-104-664-11 ELECT 47uF 20% 16V
C135 1-126-964-11 ELECT 10uF 20% 50V
C161 1-137-195-11 FILM 0.56uF 5% 50V
C162 1-136-158-00 FILM 0.027uF 5% 50V
C163 1-136-167-00 FILM 0.15uF 5% 50V
C164 1-130-480-00 MYLAR 0.0056uF 5% 50V
C165 1-136-159-00 FILM 0.033uF 5% 50V
C166 1-130-473-00 MYLAR 0.0015uF 5% 50V
C167 1-136-153-00 FILM 0.01uF 5% 50V
C168 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C169 1-130-479-00 MYLAR 0.0047uF 5% 50V
C170 1-130-477-00 MYLAR 0.0033uF 5% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C173 1-136-169-00 FILM 0.22uF 5% 50V
C174 1-136-169-00 FILM 0.22uF 5% 50V
C175 1-126-964-11 ELECT 10uF 20% 50V
C176 1-136-495-11 FILM 0.068uF 5% 50V
C177 1-136-153-00 FILM 0.01uF 5% 50V
C181 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C182 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C183 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C191 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C193 1-126-964-11 ELECT 10uF 20% 50V
C301 1-126-960-11 ELECT 1uF 20% 50V
C302 1-130-479-00 MYLAR 0.0047uF 5% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-137-194-81 FILM 0.47uF 5% 50V
C310 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-104-665-11 ELECT 100uF 20% 10V
C317 1-104-665-11 ELECT 100uF 20% 10V
C320 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C333 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C334 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C351 1-126-960-11 ELECT 1uF 20% 50V
C352 1-130-479-00 MYLAR 0.0047uF 5% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C354 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-964-11 ELECT 10uF 20% 50V
C356 1-126-960-11 ELECT 1uF 20% 50V
C357 1-126-959-11 ELECT 0.47uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-137-194-81 FILM 0.47uF 5% 50V
C401 1-126-961-11 ELECT 2.2uF 20% 50V
C411 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C412 1-163-033-91 CERAMIC CHIP 0.022uF 50V
LED (PANEL)
MAIN
To Next Page
