– 124 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Q904 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
(W300/W5000/XB500)
Q904 8-729-620-05 TRANSISTOR 2SC2603-EF
(DR4/DR5/DR6/DR440)
Q905 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
(W300/W5000/XB500)
Q906 8-729-029-21 TRANSISTOR DTA114ESA-TP
(W300/W5000/XB500)
Q907 8-729-029-21 TRANSISTOR DTA114ESA-TP
(W300/W5000/XB500)
< RESISTOR >
!R401 1-215-893-11 METAL 1.5K 5% 2W
(W300/W5000/XB500)
!R401 1-215-455-00 METAL 27K 1% 1/4W
(DR4/DR5/DR6/DR440)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB500)
R411 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB500)
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB500)
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB500)
R414 1-260-076-11 CARBON 10 5% 1/2W
(XB500)
R415 1-260-076-11 CARBON 10 5% 1/2W
(XB500)
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-247-863-91 CARBON 22K 5% 1/4W
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-249-863-91 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-412-11 CARBON 390 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
!R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
(DR4/DR5/DR6/DR440)
!R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
(DR4/DR5/DR6/DR440)
!R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
!R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-863-91 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
!R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R821 1-249-435-11 CARBON 33K 5% 1/4W
(DR4/DR6/DR440/W300/W5000/XB500)
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-247-863-91 CARBON 22K 5% 1/4W
R824 1-249-418-11 CARBON 1.2K 5% 1/4W F
R824 1-249-435-11 CARBON 33K 5% 1/4W
(DR5)
!R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-247-420-11 CARBON 1.8K 5% 1/4W
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
(DR4/DR6/DR440/W300/W5000/XB500)
R838 1-249-435-11 CARBON 33K 5% 1/4W
(DR4/DR6/DR440/W300/W5000/XB500)
!R839 1-215-877-11 METAL OXIDE 22K 5% 1W F
(DR4/DR5/DR6/DR440)
R840 1-249-402-11 CARBON 56 5% 1/4W F
!R842 1-217-637-00 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-412-11 CARBON 390 5% 1/4W F
!R855 1-215-891-11 METAL OXIDE 680 5% 2W F
!R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
!R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-247-847-31 CARBON 4.7K 5% 1/4W
(W300/W5000/XB500)
R865 1-247-863-31 CARBON 22K 5% 1/4W
(W300/W5000/XB500)
R868 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
!R889 1-215-877-11 METAL OXIDE 22K 5% 1W F
(DR4/DR5/DR6/DR440)
!R902 1-215-916-00 METAL 680 5% 3W F
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R908 1-247-807-31 CARBON 100 5% 1/4W
(W300/W5000/XB500)
R909 1-247-791-31 CARBON 22 5% 1/4W F
(DR4/DR5/DR6/DR440)
R911 1-249-429-11 CARBON 10K 5% 1/4W
(W300/W5000/XB500)
PA
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
