HCD-DX10/RG4SR/RG20/RG30T
5-13. PRINTED WIRING BOARD POWER SECTION
• See page 15 for Circuit Boards Location.
IC 501
+
_
POWER BOARD
SUB TRANS BOARD
E
TO
TRANS BOARD
CN915
(Page 29)
C
TO
MAIN BOARD
CN402
(Page 20)
TO
MAIN BOARD
CN403
(Page 20)
RG20:
AEP,UK
RG20:
AEP,UK
RG20:AEP,UK
12
12
RG4SR/RG30T
RG4SR/
RG30T
12
A
B
C
D
E
F
G
H
I
J
345678910111213
H
E
E
E
E
E
E
E
E
Ref. No. Location
D501 D-9
D502 D-7
D541 F-9
D542 B-4
D543 B-4
D551 D-7
IC501 A-8
Q501 C-9
Q503 D-9
Q504 D-8
Q551 C-7
Q581 C-8
Q582 D-10
Q583 D-10
Q584 D-11
• Semiconductor
Location
